High Power Density LiFePO4 Lithium Iron Phosphate Battery 12V 80Ah Replacement for Lead Acid
High Power Density LiFePO4 Lithium Iron Phosphate Battery 12V 80Ah Replacement for Lead Acid
Specifications
Size :
L*W*H=260*167*210mm
Rating Voltage :
12V
Impedance :
15mΩ（Max）
Weight approx :
8.6kg
Operating Temperature :
Charging 0~45℃
Certification :
CE,UL,ROHS
Payment Terms :
L/C,D/A,D/P,T/T in advance
Supply Ability :
10000PCS/30Days
Delivery Time :
20Days
Packaging Details :
Carton
Capacity :
80Ah
Storage Temperature :
-10℃-40℃ Recommend（25±5℃）
Charge Voltage :
14.6V±0.05V
Cell Type :
LiFePO₄
Brand Name :
FBATTERY
Model Number :
FB-1280
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Description
High Power Density LiFePO4 Lithium Battery Replacement Lead Acid 12V 80Ah Powerful
High Power Density LiFePO4 Lithium Battery designed as a direct replacement for lead acid batteries, offering superior performance and reliability.
Specifications
No Item Parameter Remark
1 Rating Voltage 12.8V
2 Capacity 80Ah 0.5C discharge after full charge
Minimum Capacity 78AH
3 Charge Voltage 14.6V±0.05V
4 Impedance 15mΩ(Max)
5 Charging Mode C.C/C.V. Constant Current / Constant Voltage
6 Charging Method Standard Charging Charging Current 12A
Fast Charging Charging Current 40A
7 Charging Time Standard Charging 7.5 Hours
Fast Charging 2.6 Hours
9 Overcharge Voltage 3.65±0.05V
10 Over Discharge Cut Off Voltage 2.2V±0.1V
11 Over Current 200-300A
12 Short Circuit
13 Operating Consumption Current 50uA(MAX)
14 Operating Temperature Charging: 0~45℃
Discharging: -10~60℃
15 Storage Temperature -10℃-40℃ Recommend(25±5℃) Storage capacity should be 40%~50% full charge capacity
16 NTC Resistor /
17 ESD Test ±4KV
18 Discharge current ≤80A
19 The factory voltage 12.8-13.6V The open circuit state
20 Weight Approx 8.6KG
Storage Guidelines

The battery storage shall be in a clean, dry, and well-ventilated room at temperatures between -5℃ to 35℃. Keep batteries away from fire, heat sources, and corrosive elements.

Batteries should be charged every 3 months during storage. Follow the "first come, first use" principle for both stored cells in process and batteries in delivery.

The battery storage period is 24 months from warehouse entry. Batteries exceeding this period must undergo thorough inspection. Only applicable batteries can be dispatched to purchasers; inapplicable units shall be rechecked, and purchasers retain the right to dispose of defective batteries.
