CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
Specifications
Brand Name :
OUCO
Model Number :
OCM-800S
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
CE Certification 800T Orange Plastic Injection Molding machine Making Garbage Bin
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

CE Certification 800T Orange Plastic Injection Molding machine Making Garbage Bin

OUCO is one of the world's leading manufacturers of machinery and systems for the production and processing of rubber and plastics and was founded many years ago. We offer injection moulding machinery and solutions to cover all areas. Thanks to our innovative competence in standardised and individual products, processes, digital service solutions and much more, OUCO helps our customers to achieve sustainable growth with continuous added value along the entire value-added chain. The origin of artisanal technology and many years of heritage and development make OUCO unique in the global marketplace. Our broad portfolio of products and technologies serves customers in a wide range of industries, including manufacturers of automotive, packaging, medical, construction, electrical and electronic products and household appliances.
Features and advantages:

Product Advantages

1. Wide application: household daily necessities, widely used in auto parts, chairs, plastic pots, bins, etc. Provide customised service to meet your individual needs.
2. Specialised screws: special screws and barrels are configured for different characteristics of plastics to ensure the quality of products. Sturdy and durable, low maintenance cost.
3. High flexibility: faster response to market changes, keep pace with the times, advanced technology, maintain competitive advantage.
4. High Repeatability: Stable hydraulic system ensures a high degree of consistency in product quality. No matter how many batches are produced, the quality of the product remains consistent, providing a better customer experience.
5. Linear guides and moving formwork frame structure: not only ensure high parallelism of formwork, but also improve positioning accuracy. Multi-stage injection holding pressure storage pressure, speed and position control.
6. Highly energy-saving: high-performance servo drive, more energy-saving and lower running cost.

Parameters

MODEL OCM-800S
Clamping force (kN) 800
Space between tie bar (mm*mm) 1070*970
Max. mold thickness (mm) 1200
Min. mold thickness(mm) 500
Opening stroke (mm) 2500
Ejector stroke(mm) 280
Ejector force forward(Kn) 212
Screw diameter(mm) 75
Screw L/D ratio 21
Theoretical injection volume (cm3) 1590
Shot weight (PS) g 1462
Injection pressure(MPa) 178
Injection speed (mm/s) 170
Injection rate (g/s) 750
Motor power (Kw) 107.5
Oil tank capacity(L) 900
Heater power (Kw) 30.02
Machine Weight (kg) 35
Machine size L×W×H (mm) 9400*2600*2600

Detail Pictures
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage BinCE Certification 800T Orange Plastic Injection Molding Machine Making Garbage BinCE Certification 800T Orange Plastic Injection Molding Machine Making Garbage BinCE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin

CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
Company Profile
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
CE Certification 800T Orange Plastic Injection Molding Machine Making Garbage Bin
