Specifications
Brand Name :
OUCO
Model Number :
OUCO-PV1100T
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
PVC Injection Molding Machine For Fruit Packing and Shopping Basket Foldable Crates
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

PVC Injection Molding Machine For Fruit Packing and Shopping Basket Foldable Crates

Product Details
1. PVC material with special screw + barrel design and added fan for cooling barrel to avoid material overheating and coking;

2. Add a larger grade of oil motor to facilitate the plasticization and molding of PVC material;

3. Extended security door width for better installation of PVC parts molds, suitable for easy installation of PVC parts molds (core extraction barrels);

4. Provide special technical solutions for PVC injection molding, not only for the modification of screw and barrel, but also for the complete hydraulic system and special solutions for injection device.

TECHNICAL PARAMETER TABLE
Injection Unit
Screw diameter mm 120
Screw L/D ratio L/D 20.2
Injection capacity in theory cm³ 6333
Injection weight(PVC) g 7600
Injection pressure MPa 150
Injection rate g/s 1123
Plasticizing capacity g/s 134
Screw speed rpm 110
Clamping Unit
Clamping force KN 11000
Moving mould-plate stroke mm 1220
Max.Mould height mm 1170
Min.Mould height mm 450
Space between tie-bars mm 1160x1160
Hydraulic ejector force KN 245
Hydraulic ejector stroke mm 320
Ejector number n 21
Other
Pump pressure MPa 16
Motor/Driving power KW 30x3
Heating capacity KW 68.85
Machine dimension m 12.55x3.25x3.5
Machine weight t 56.3
Oil tank capacity L 2000
