Specifications
Brand Name :
OUCO
Model Number :
OUCO-PV298T
Certification :
CE, ISO9001:2008, SGS
Place of Origin :
Wuxi,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 sets/year
Delivery Time :
2 months
Packaging Details :
Nude
Product Name :
OUCO 298 Ton PVC Injection Molding Machine With Standard Screw Configurations
Plastic Processed :
PP,PC,PVC
Applicable :
Manufacturing Plant,Food&Beverage
Type :
Automation
Warranty :
1 Year
Machinery :
Provided
Selling Points :
Competitive Price
Video Outgoing-inspection :
Provided
Machine Style :
Horizontal
Condition :
New
Lead Time :
About 50 Days
Description

OUCO 298 Ton PVC Injection Molding Machine With Standard Screw Configurations

OUCO is a factory specialized in supplying one of the market leaders in the supply of machinery for the processing of PVC injection molding.

Modern grades of rigid PVC are also less thermally stable, and soft PVC can usually be processed on standard injection molding machines. OUCO adopts standard screw configurations to meet customer needs. Rigid PVC requires special machinery to be applied, which we have the expertise to customize to ensure optimum processing conditions.

TECHNICAL PARAMETER

TECHNICAL PARAMETER TABLE
Injection Unit
Screw diameter mm 60
Screw L/D ratio L/D 20.6
Injection capacity in theory cm³ 820
Injection weight(PVC) g 984
Injection pressure MPa 168
Injection rate g/s 324
Plasticizing capacity g/s 52
Screw speed rpm 180
Clamping Unit
Clamping force KN 2980
Moving mould-plate stroke mm 600
Max.Mould height mm 690
Min.Mould height mm 230
Space between tie-bars mm 605x590
Hydraulic ejector force KN 80
Hydraulic ejector stroke mm 150
Ejector number n 13
Other
Pump pressure MPa 16
Motor/Driving power KW 30
Heating capacity KW 18.15
Machine dimension m 6.5x2.15x2.08
Machine weight t 8.2
6Oil tank capacity L 415
