Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine
Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine
Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine
Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine
Specifications
Brand Name :
OUCO
Model Number :
OUCO-700T
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
35 work days
Price :
Negotiable
Supply Ability :
500 sets per year
Packaging Details :
shipping container
Product Name :
Low Price InjectiLow Price Injection Molding Machine Clamping Force 700 Tonon Molding Machine Clamping Force 700 Ton
Type :
Automation
Function :
Plastic Parts Production
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

Low Price Injection Molding Machine Clamping Force 700 Ton

This deep cavity clamping force 700T injection molding machine is outward turning crankshaft, it make the same clamping force injection machine have the longer opening stroke .

Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine

Why choose OUCO injection molding machine?

A: Unique Quality .Parts is provided by well-known manufacturers, such as Schneider ,Siemens.

B: Competitive price.Equipment for the same purpose, our price is lower.

C: Outstanding Service . 8+8+8 service system, both after-sales and sales are proficient in injection molding machines.

Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine

The hydraulic system is provided by well-known manufacturers in China and is designed and manufactured with high-speed super large and special oil circuit.It adopts multi-channel logic control with large flow, low noise and stable performance.The machines with a capacity of more than 450 tons provide the synchronous function of ejector pin while opening the moldso as to shorten the forming cycle of the product.

Automation Clamping Force Injection Molding 700 Ton Injection Molding Machine

Model 600T 700T
Screw Model C A B C A B C
Screwdi ameter mm 85 75 85 90 85 90 100
Screw L/Dratio 22 22 22 22 22 22 22
Theoretical injection volume cm3 2184 1788 2297 2575 2552 2861 3533
Shot weight (PS) g 2031 1645 2113 2369 2348 2632 3250
injection rate(Ps) g/S 890 G13 788 884 788 883 1091
Injection pressure MPa 142 204 159 142 209 187 151
Inject on stroke mm 405 450
Max. injection speed mm/s 157 147
Screw speed r/min 0-200 0-180
Sys. Pressure MPa 16 16
Pump Motor(Min-Max) kW 101 114
Displacement ml/r 160+125 160+160
number of Motors PC 2 2
Heater power kW 47 52
Number oftemp. control zones 5+1 5+1
Clamping force kN 6000 7000
Opening stroke mm 1150 1300
Tie bar distance W×L mmxmm 960x860 1020x920
Min. mold thickness mm 350 450
Max. mold thickness mm 920 1050
Ejector stroke mm 210 210
Ejector force forward kN 113 113
Number of ejector bar PC 1+12 1+12
Oil tank capacity L 940 1020
Machine dimensions(LxWxH) mxmxm 9.3x2.1x2.3 9.7x2.2x2.4
Machine weight Ton 23 25

All of our deep cavity injection molding machine are equipped with double servo motor power,it control adopts the latest confluence technology

Our company's lubrication system uses copper pipes for fixed pipes and soft copper pipes for moving parts, which can increase the service life of copper pipes.

The hydraulic system is provided by well-known manufacturers in China and is designed and manufactured with high-spespeed super large and special oil circuit adopts multi-channel logic control with large flow, low noise and stable performance.The machines with a capacity of more than 450 tons provide the synchronous function of ejector pin while opening the mold so as to shorten the forming cycle of the product.
