Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Servo Injection Plastic Making Machine CWI-400GB
Specifications
Brand Name :
OUCO
Model Number :
CWI-450GB
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 sets per year
Delivery Time :
1 months
Packaging Details :
shipping container
Product Name :
Servo Injection Plastic Making Machine CWI-400GB
Type :
Automation
Function :
Plastic Parts Production
Motor :
Servo Energy Saving
Color :
Support customization
Stable Performance :
Short Cycle Time
Clamping Way :
Hydraulic
Transport Package :
FCL
Description

Servo Injection Plastic Making Machine CWI-400GB

Jiangsu OUCO Heavy Industry Technology Group was founded in February 1984. The company is located in the beautiful Taihu Lake, the foot of Lingshan Mountain, is a high-tech enterprise in Wuxi Huishan District Yangshan Industrial Park. In 2021, the Group invested to establish OUCO (Wuxi) injection molding machinery equipment Co., Ltd. The company covers an area of 35,000 square meters, and the factory covers 25,000 square meters. The company is committed to developing and manufacturing high-quality and high-performance injection molding equipment for automotive parts, medical equipment, large pipe fittings, garbage cans, trays, fruit baskets and other market fields, and customizing efficient, energy-saving and professional production solutions for customers.

OUCO creates a new G-Series product with European standards. SV servo energy-saving system has 8 specifications with clamping force ranging from 110 tons to 600 tons. Each specification can also be selected with 2 or 3 different injection structures according to customer product requirements.

The passionate pursuit of perfection. OUCO has always been committed to meet the needs of customers, create more value for customers is the super injection eternal ideas. we will, as always in the market front, fear hardships and challenges, in energy conservation, automation, machine motors, humanization aspects of continuous efforts, bring customers the greatest return on investment.

Parameters

Model 300T 400T 500T
Screw Specifications A B C A B C A B C
Screwdi ameter mm 50 60 65 65 75 80 70 75 85
Screw L/Dratio 22 22 22 22 22 22 22 22 22
Theoretical injection volume cm3 638 918 1078 1C75 1431 1628 1481 1700 2184
Shot weight (PS) g 593 853 1002 1C11 1345 1530 1377 1581 2031
injection rate(Ps) g/S 330 475 558 426 568 646 G03 693 890
Injection pressure MPa 286 198 169 242 182 160 209 182 142
Inject on stroke mm 325 360 385
Max. injection speed mm/s 178 156 166
Screw speed r/min 0-200 0-200 0-200
Sys. Pressure MPa 16 16 16
Pump Motor(Min-Max) kW 63 75 94
Displacement ml/r 163 100+100 125+125
number of Motors PC 1 2 2
Heater power kW 27 35 41
Number oftemp. control zones 5+1 5+1 5+1
Clamping force kN 3000 4000 5000
Opening stroke mm 800 900 1000
Tie bar distance W×L mm*mm 680x680 760x660 860x760
Min. mold thickness mm 210 300 300
Max. mold thickness mm 680 730 800
Ejector stroke mm 190 190 210
Ejector force forward kN 62 80 110
Number of ejector bar PC 1+12 1+12 1+12
Oil tank capacity L 510 680 850
Machine dimensions(LxWxH) m*m*m 7.7x1.8x1.8 8.2x1.9x1.9 87x2.0x2.1
Machine weight Ton 10.5 15 19
