Specifications
Brand Name :
E-link
Model Number :
LNK-IMC1200P Series
Certification :
ISO
Place of Origin :
China
MOQ :
1 unit
Price :
$39-270
Payment Terms :
T/T, Western Union, MoneyGram,PayPal
Supply Ability :
10000pcs/Month
Delivery Time :
5-10 working days
Packaging Details :
Fiber Media Converter Standard Package
Feature :
IEEE 802.3az Energy Efficient Ethernet (EEE)
PoE Standard :
IEEE802.3at Power over Ethernet
Forward Filter Rate :
148,800pps (100Mbps)
Connector NO. :
2 x RJ45
Optical Port :
1 x SC 100Base-FX
Mounting :
DIN-Rail / Wall-mount
Description

Mini Industrial 100M Multimode Fast Fiber Media Converter SC RJ45 Ethernet

PoE+ Media Converter

​Fiber Media Converter Advantages

  • 2-port 10/100BASE-T RJ45 with auto MDI/MDI-X function
  • 1-Port 100Base-FX SC
  • 12~48VDC Terminal Block Power Input

Specifications

Interface

Connector:

2 x RJ45

Optical Port:

1 x SC 100Base-FX

Electrical and Mechanical

Input Power:

12~48VDC, 2-pin terminal block

Output Power

48VDC

Power Consumption:

65W Max.

Dimensions (WxDxH):

95 x 70 x 30 mm

Weight:

0.25Kg

Casing:

Aluminum Case

Mounting Options:

DIN-Rail / Wall-mount

Environmental

Operating Temperature:

-40°C to 75°C (-40°F to 167°F)

Storage Temperature:

-40°C to 85°C (-40°F to 185°F)

Mini Industrial 100M Multimode Fast Fiber Media Converter SC RJ45 Ethernet PoE+ Media Converter

Order Information

Model Description
LNK-IMC1200P Mini Industrial PoE Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T 802.3at PoE, SC Fiber Port, Multimode, 1310nm, 2km
LNK-IMC1200P-20 Mini Industrial PoE Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T 802.3at PoE, SC Fiber Port, Single Mode, 1310nm, 20km
LNK-IMC1200PS-20 Mini Industrial PoE Media Converter, 1-port 100BASE SC + 2-port 10/100BASE-T 802.3at PoE, SC Fiber Port, Single Mode Single Fiber, 1310/1550nm, 20km
Mounting Options ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options ► 75W/1.6A 48VDC Power Supply. Open Wire for Terminal Block
► Power Supply is to be purchased separately.
