360V-520V Induction Melting Equipment 40KW Induction Heating Device
360V-520V Induction Melting Equipment 40KW Induction Heating Device
Specifications
Brand Name :
InductionFusion
Model Number :
IF-40
Certification :
CE, SGS , ROHS
Place of Origin :
china
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T,Western Union
Supply Ability :
500set/month
Delivery Time :
7~15days
Packaging Details :
wooden box
Net weight :
28kg
Cooling water :
≥6L/min (1.6 gallons)
Output frequency :
30-80KHz
Input voltage :
3Phase 380V 50/60Hz
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant
Core Components :
PLC, Motor
Description

Induction Melting Equipment with 40KW Induction Heating device

Key attributes

Work power 360V-520V
Maximum input current 65A
Output power 40kw
Fluctuating frequency 20-50khz
Output current 400-1800A
The flow rate of cooling water 0.08-0.16Mpa 9L/Min
Water temperature protection point 50C
Product size main : 690x600x1060mm
transformer : 570x290x470mm
Net weight main : 60kgs
transformer : 28kgs

Major Features

  1. CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW adopts Soft-switch ultrahigh frequency technology and two poles closed loop control technology; and our company fully owns the independent intellectual property rights

  2. Fluctuating frequency can be 100K-1.5MHZ, control the depth of surface quenching, which can totally replace the high frequency of vacuum tube.

  3. CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW can continuously work for 24 hours, and 100% duty cycle.

  4. Parts of power devices are all from well-know brand products

  5. Ultra-small size and weight; High efficiency, energy saving and environmental protection with safety.


Customization options
Customized logo (Min. order: 1 piece)
Customized packaging (Min. order: 1 piece)
Graphic customization (Min. order: 1 piece)

360V-520V Induction Melting Equipment 40KW Induction Heating Device

360V-520V Induction Melting Equipment 40KW Induction Heating Device
360V-520V Induction Melting Equipment 40KW Induction Heating Device
About service question:

Q:How to choose suiteble machine?
A:You can tell us your application,need forging,hardening,welding,melting or other,pass me workpiece material & size,Temperature requirement and heating time requirement.Then we will recommend fit machine for you reference.

Q:How about the machine delivery time?
A: Small machine delivery time is 3~7 workdays.Big machine delivery time 15~25 workdays.

Q:How about the machine warranty?
A:Our goods support one year warranty not by personal purpose,support technical service all life.
During the warranty,if machine have problem need change spare parts,we can replace for you charge free.
