Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Precision Cutting Tooling For 10kg Washing Machine Drum Compatible With 12kg Models
Specifications
Brand Name :
IDO
Model Number :
Washing Machine Drum
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$10000-$50000
Payment Terms :
L/C,T/T
Supply Ability :
300 sets/year
Delivery Time :
45days
Packaging Details :
Wooden Case, Anti-Rust Oil, Vacuum Packaging
Product Type :
Cutting Tooling
Application :
Washing Machine Drum
Supported Capacity :
10kg (Compatible with 12kg Models)
Process :
Sheet Metal Cutting
Tooling Material :
Tool Steel
Drum Material :
Stainless Steel / Sheet Metal
Mould Life :
1,000,000 shots
Standard Parts Brand :
MISUMI
Description

Precision Cutting Tooling for 10kg Washing Machine Drum Compatible with 12kg Models


Description

This precision cutting tooling is specially designed for sheet metal forming of washing machine inner drums, optimized for 10kg drum structures while remaining compatible with 12kg washing machine models.

Through precise cutting layout and optimized tooling structure, the tooling ensures consistent hole patterns, stable drum strength and reliable performance, helping manufacturers reduce tooling investment while increasing production flexibility.

Key Features

  • Dual Capacity Compatibility
    One tooling set supports 10kg inner drum production and is compatible with 12kg washing machine configurations, improving tooling utilization efficiency.

  • High Precision Cutting
    Accurate cutting ensures uniform hole size, spacing and edge quality, which is essential for drum balance and long-term operational stability.

  • Stable Tooling Structure
    Manufactured with high-strength tool steel, the tooling maintains dimensional stability under continuous cutting operations.

  • Optimized for Cylindrical Drum Forming
    Designed specifically for curved inner drum geometry, supporting complex perforation layouts.

  • Cost-Effective Production Solution
    Reduces the need for multiple tooling sets when producing different capacity washing machine models.

Competitive Advantages

  • One tooling set for multi-capacity washing machine platforms

  • Precise cutting improves inner drum balance and appearance

  • Stable quality for mass production lines

  • Reduced tooling investment and changeover time

  • Custom design based on customer drawings or samples


Specifications:

Mould/Tool Type
Stage tool/mould/die
Production Application
White Household Appliances (washing machine, refrigerator, dryer, dishwasher…), Automobile (heat shield, radiator...)
Metal Sheet Material
Stainless Steel (304, 430...), PCM, VCM, SGCC, Aluminum (6061, 6063,7075...), Copper
Mould Material
V8, ASP60, P20, ASSAB88, XW-42, SKD11, DC53, CR12MOV, AMPCO25
Mould Base
SD, LKM Standard, HASCO Standard, Self-made, etc.
Tolerance
±0.003mm
Hardness
Upon request
Surface Treatment
TiCN/ Polishing/ mirror polishing/ plating/ heat treatment / Deep Cooling or according to your parts
Precision Machining
CNC/ surface grinding machine/ wire cutting/ EDM
Measuring Instruments
CMM/ Profile projector/ electronic height gauge/ spectrum analyzer / caliper/ microscope/ micrometer, etc.
Drawing Format
DWG, STP, STEP, X_T, IGES, PDF
Design Software
Auto CAD, UG, Solidworks
Trade terms
FOB (Shanghai)
Mould Lead time
Generally 6~8 weeks (as per actual situation)
