High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
High Precision Stamping Die For Automotive Engine Head Gasket
Specifications
Brand Name :
IDO
Model Number :
Automotive Head Gasket
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$10000-$50000
Payment Terms :
L/C,T/T
Supply Ability :
300 sets/year
Delivery Time :
45days
Packaging Details :
Wooden Case, Anti-Rust Oil, Vacuum Packaging
Die Construction Material :
High-strength tool steel for long-term use
Thickness Capability :
Adapted to gasket design and sealing performance requirements
Stamping Accuracy Level :
Consistent dimensional repeatability in long production cycles
Profile & Edge Control :
Precise contour definition with clean sealing edges
Structural Design Focus :
Rigidity, wear resistance, and operational stability
Production Environment :
Suitable for automated and high-volume stamping lines
Mould Life :
1,000,000 shots
Standard Parts Brand :
MISUMI
Description

High Precision Stamping Die for Automotive Engine Head Gasket


Description

The Automotive Head Gasket Sheet Metal Stamping Die is engineered for high-precision stamping and forming of head gaskets used in automotive engines.
With a rigid die structure and optimized stamping design, the die ensures accurate profile forming, stable dimensional consistency, and reliable sealing surface quality, which are critical for engine performance and durability.

Manufactured from premium-grade die steel and processed with advanced machining technology, this stamping die delivers stable operation, high production efficiency, and extended service life. It is suitable for continuous and high-volume production, and can be customized according to different engine platforms, head gasket designs, material compositions, and thickness requirements, making it a dependable solution for automotive parts manufacturers and OEM suppliers.


Quick Detail

  • Product Name: Automotive Head Gasket Sheet Metal Stamping Die

  • Die Type: Stamping Die

  • Application: Automotive Engine Head Gasket Production

  • Component Category: Engine Sealing Parts

  • Process Method: Sheet Metal Stamping & Forming

  • Compatible Materials: Stainless Steel / Carbon Steel / Multi-layer Metal Sheets

  • Key Advantages: High precision forming, stable sealing edge quality, long die service life

  • Production Mode: Continuous / High-volume Production

  • Customization: Supported (engine model, gasket profile, material structure)


Specifications:

Mould/Tool Type
Stage tool/mould/die
Production Application
White Household Appliances (washing machine, refrigerator, dryer, dishwasher…), Automobile (heat shield, radiator...)
Metal Sheet Material
Stainless Steel (304, 430...), PCM, VCM, SGCC, Aluminum (6061, 6063,7075...), Copper
Mould Material
V8, ASP60, P20, ASSAB88, XW-42, SKD11, DC53, CR12MOV, AMPCO25
Mould Base
SD, LKM Standard, HASCO Standard, Self-made, etc.
Tolerance
±0.003mm
Hardness
Upon request
Surface Treatment
TiCN/ Polishing/ mirror polishing/ plating/ heat treatment / Deep Cooling or according to your parts
Precision Machining
CNC/ surface grinding machine/ wire cutting/ EDM
Measuring Instruments
CMM/ Profile projector/ electronic height gauge/ spectrum analyzer / caliper/ microscope/ micrometer, etc.
Drawing Format
DWG, STP, STEP, X_T, IGES, PDF
Design Software
Auto CAD, UG, Solidworks
Trade terms
FOB (Shanghai)
Mould Lead time
Generally 6~8 weeks (as per actual situation)
