Flyback Transformer BOURNS 063934 with Nominal Inductance 0 89 Millihenry and 400 Volt Working Voltage
Flyback Transformer BOURNS 063934 with Nominal Inductance 0 89 Millihenry and 400 Volt Working Voltage
Specifications
Isolation Voltage(Vrms) :
4.2kV
Primary Side Voltage :
85~265V
Description :
4.2kV 85~265V DIP-8P,22x19mm Switching Converter, SMPS Transformers RoHS
Mfr. Part # :
063934
Model Number :
063934
Package :
DIP-8P,22x19mm
Description

Product Overview

The Bourns Model 063934 SP-E 16/5 is a Flyback Transformer designed for switched-mode power supplies (SMPS). It features reinforced insulation, offering a 400 V working voltage and assisting in compliance with EN 62368, EN 60335, and EN 61558 standards. This VDE-approved and RoHS compliant transformer is suitable for AC-DC conversion applications.

Product Attributes

  • Brand: Bourns
  • Model Number: 063934 SP-E 16/5
  • Certifications: VDE approved
  • Compliance: RoHS Directive 2015/863
  • Insulation: Reinforced insulation 400 V working voltage
  • Standards Assistance: EN 62368, EN 60335, EN 61558

Technical Specifications

Specification Value
Nominal Inductance @ 50 mV / 10 kHz 0.89 mH 10 %
Maximum Transmissible Power 9 W
Working Frequency Range 44 to 132 kHz
Transformation Ratio 9.6 : 4.69 : 1 : 1
Dielectric Strength (Primary-Secondary) 4.2 kV/50 Hz/1 sec.
Leakage Inductance 50 H max.
Operating Temperature -25 C to +125 C
Storage Temperature -25 C to +85 C
Product Dimensions (L x W x H) 11.43 0.3 (.450 .012) x 17.78 0.3 (.700 .012) x 5.08 0.3 (.200 .012) (approx.)
Pin Pitch (Typical) 2.54 mm (.100)
Packaging Bulk (250 pcs. per tray)
Input Voltage 85-265 VAC
Output Voltage/Current (Uout1, Uout2) 12 V / 0.37 A (each)
Winding Designations AI, AII, AIII, AIV (Start of Winding); EI, EII, EIII, EIV (End of Winding)

Applications

  • Flyback transformer with reinforced insulation for switched-mode power supplies
  • Designed for use in SMPS applications based on semiconductors from various AC-DC conversion silicon manufacturers

2411261505_BOURNS-063934_C19945835.pdf
