Compact Reinforced Insulation Flyback Transformer BOURNS 094929 for Switched Mode Power Supply Designs
Compact Reinforced Insulation Flyback Transformer BOURNS 094929 for Switched Mode Power Supply Designs
Specifications
Isolation Voltage(Vrms) :
4.2kV
Primary Side Voltage :
85~265V
Description :
4.2kV 85~265V DIP-15P,25x21mm Switching Converter, SMPS Transformers RoHS
Mfr. Part # :
094929
Model Number :
094929
Package :
DIP-15P,25x21mm
Description

Product Overview

The Bourns 094929 SP-E 20/6 Flyback Transformer is designed for switched-mode power supplies (SMPS) requiring reinforced insulation. It offers a working voltage of 400 V and assists in compliance with EN 62368, EN 60335, and EN 61558 standards. This VDE approved and RoHS compliant transformer is suitable for AC-DC conversion applications based on various semiconductor manufacturers.

Product Attributes

  • Brand: Bourns
  • Model: 094929 SP-E 20/6
  • Certifications: VDE approved, RoHS compliant
  • Insulation: Reinforced insulation

Technical Specifications

Specification Value
Nominal Inductance @ 50 mV / 10 kHz 0.94 mH 10 %
Maximum Transmissible Power 22 W
Working Frequency 132 kHz
Transformation Ratio 8.78 : 1.1 : 1 : 1
Dielectric Strength (50 Hz / 1 s) WI/WII - WIII/WIV = 4.2 kV / 50 Hz / 1 sec.
Leakage Inductance 35 H max.
Operating Temperature -25 C to +125 C
Storage Temperature -25 C to +85 C
Working Voltage 400 V
Dimensions (L x W x H) 15 x 17.5 x 3.5 mm (0.591 x 0.689 x 0.138 in)
Packaging Specifications Bulk: 250 pcs. per tray
Schematic Input Voltage 85-265 VAC
Schematic Output Voltage/Current Uout1: 12 V / 0.9 A, Uout2: 12 V / 0.9 A

Features

  • High clearance and creepage distance transformer
  • Reinforced insulation 400 V working voltage
  • Assists in compliance with EN 62368, EN 60335 and EN 61558 standards
  • VDE approved
  • RoHS compliant

Applications

  • Flyback transformer with reinforced insulation for switched-mode power supplies
  • Designed for use in SMPS applications based on semiconductors from various AC-DC conversion silicon manufacturers
