VDE Approved Flyback Transformer BOURNS 093830 SP E 16 5 for Switched Mode Power Supply Applications
VDE Approved Flyback Transformer BOURNS 093830 SP E 16 5 for Switched Mode Power Supply Applications
Specifications
Isolation Voltage(Vrms) :
4.2kV
Primary Side Voltage :
85~265V
Description :
4.2kV 85~265V DIP-8P,22x19mm Switching Converter, SMPS Transformers RoHS
Mfr. Part # :
093830
Model Number :
093830
Package :
DIP-8P,22x19mm
Description

Product Overview

The Bourns 093830 SP-E 16/5 Flyback Transformer is designed for switched-mode power supplies (SMPS) and applications requiring reinforced insulation. It offers high clearance and creepage distance, supporting compliance with EN 62368, EN 60335, and EN 61558 standards. This VDE approved and RoHS compliant transformer is suitable for AC-DC conversion based on various semiconductor manufacturers.

Product Attributes

  • Brand: Bourns
  • Product Line: SP-E
  • Certification: VDE approved
  • Compliance: RoHS compliant*
  • Insulation: Reinforced insulation 400 V working voltage

Technical Specifications

Specification Value
Model Number 093830 SP-E 16/5
Nominal Inductance 1.58 mH 12 %
Maximum Transmissible Power 8 W
Working Frequency 132 kHz
Transformation Ratio 4 : 18,5 : 1 : 1
Dielectric Strength Primary-Secondary 4.2 kV/50 Hz/1 sec.
Leakage Inductance 62 H max.
Operating Temperature -25 C to +125 C
Storage Temperature -25 C to +85 C
Dimensions (L x W x H) 11.43 0.3 (.450 .012) x 17.78 0.3 (.700 .012) x 5.08 0.3 (.200 .012) mm (inches)
Packaging Bulk: 250 pcs. per tray

Features

  • High clearance and creepage distance transformer
  • Reinforced insulation 400 V working voltage
  • Assists in compliance with EN 62368, EN 60335 and EN 61558 standards
  • VDE approved
  • RoHS compliant*

Applications

  • Flyback transformer with reinforced insulation for switched-mode power supplies
  • Designed for use in SMPS applications based on semiconductors from various AC-DC conversion silicon manufacturers

Important Information

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth at www.bourns.com/docs/legal/disclaimer.pdf.


2411261505_BOURNS-093830_C19945838.pdf
