300W 72MHz to 76MHz VHF High Power Drop In Circulator
300W 72MHz to 76MHz VHF High Power Drop In Circulator
Specifications
Place of Origin :
Chengdu,China
Model Number :
ZSHX72-76-20DP300
Brand Name :
Zysen
MOQ :
1pc
Price :
Negotiable
Delivery Time :
2-4 Weeks
Payment Terms :
T/T, L/C,D/A
Certification :
ISO9001
Description

72 to 76MHz 300W High Power Drop in Circulator

Coaxial Circulator

Zysen offers Coaxial Circulator, cover low band VHF, UHF from 30MHz and high frequency band to 40GHz, power handle up to 1KW,Connector SMA, N or Tab are avaliable. Customized frequency and optimized specifications available. Contact us with your requirement.

P/N Freq. Range
(MHz)		 Insertion Loss
(dB)
max		 Isolation
(dB)
min		 VSWR
max		 Average Power
(W)		 Connector
ZSHX56-86-18D 56-86 1.2 18 1.30 100 Tab
ZSHX60-70-20N 60-70 1.0 20 1.25 50 N
ZSHX72-76-20DP300 72-76 0.8 20 1.25 300 Tab
ZSHX125-131-23N 125-131 0.5 23 1.20 50 N
ZSHX300-400-20D 300-400 0.5 20 1.25 10 Tab
ZSHX600-800-20S 600-800 0.5 20 1.25 50 SMA
ZSHX1700-2700-20N 1700-2700 0.5 20 1.25 200 N
ZSHX2000-4000-18S 2000-4000 0.6 18 1.35 10 SMA
ZSHX4000-8000-18S 4000-8000 0.6 18 1.35 5 SMA
ZSHX5872-20D 5800-7200 0.4 20 1.25 10 Tab
ZSHX80120-20D 8000-12000 0.6 18 1.30 10 Tab
ZSHX95117-20D 9500-11700 0.4 20 1.25 20 Tab
ZSHX100150-18D 10000-15000 0.6 18 1.35 20 Tab
ZSHX120180-18D 12000-18000 0.6 18 1.30 20 Tab
ZSHX177212-18S 17700-21200 0.7 18 1.30 2 SMA
