SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
Specifications
Brand Name :
DME&JDE
Model Number :
SCM120A-PRO
Certification :
MSHA & BV & GOST & IATF 16949 & ISO 9001 & ISO 14001 & ISO 45001 & DAKKS & SGS & MA & DEKRA
Place of Origin :
Hengshui City, Hebei Province, China
MOQ :
1 Piece (MOQ)
Price :
US$4,100.00-5,700.00
Payment Terms :
T/T
Supply Ability :
1 Piece (MOQ) 20 days
Delivery Time :
30 days
Packaging Details :
wallet
Productname :
Hose Assembly Equipment
Control :
Number control
Crimp range :
1/4" to 2-1/2"
Max. opening without dies :
122mm
Max. die opening :
28mm
Motor & Voltage :
3 kW / 380 V
Type :
Industrial Equipment
Foot pedal :
Included Noise level
Dimensions :
820mm x 615.67mm x 1200mm
Die sets :
12 sets
Description

SCM120A Pro Hose Assembly Equipment | Professional Hydraulic Crimper Machine

Hose Assembly Equipment Product Name

DME&JDE SCM120A-Pro hydraulic hose crimping machine is an flexible and multi-functional design. Compact design and slim structure conforms to rgonomics and smart control system make it high user-friendliness. It is applicable for crimping of 4 or 6 spiral wires reinforcement hoses up to 2-1/2 inches diameters.

It is also an innovative design. Bright colors, lights designs as well as logo and model display will redefine the crimping machine and will lead a fashion way.

Crimping Machine Technical Data
Crimp head material Forge steel
Crimp range 1/4" to 2-1/2"
Max. opening without dies 122mm
Max. die opening 28mm
Motor & Voltage 3 kW / 380 V
Cycle time 7 seconds
Oil tank volume 65 L
Control Number control
Foot pedal Included
Noise level 69dB
Die sets 12 sets
L × W × H 820 × 615.67 × 1200 mm
High Pressure Dies Specification
Number Die No. Crimp Range (mm) D (mm ) L (mm)
1 14 14-16 14 65
2 16 16-19 16 65
3 19 19-22 19 65
4 22 22-26 22 65
5 26 26-30 26 65
6 30 30-34 30 65
7 34 34-39 34 70
8 39 39-45 39 70
9 45 45-51 45 80
10 51 51-57 51 80
11 57 57-63 57 90
12 63 63-69 63 90
