Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
Specifications
Brand Name :
Jiayan
Model Number :
CPRV
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, PayPal
Supply Ability :
500 sets per week
Delivery Time :
7 days
Packaging Details :
poly bag and carton box
Material :
carbon steel
Max Withstanding Pressure :
500kg/cm2
Pressure Range :
5-380kg/cm2
Type :
lIne type or manifold type
Warranty :
1 year (change new one for free)
Surface :
blackening treatment
Description

Hydraulic Pressure Reducing Valve Compact Size Carbon Steel With Treatment on Surface

Features:

1. compact size and structure

2. long life expectancy

3. light weight

4.The pressure reducing valve is a pressure control valve that uses a flow of liquid to flow through the gap to make the outlet oil pressure lower than the inlet oil pressure to meet the needs of the actuator.

5.

● Recommended viscosity : The recommended viscosity for normal work is 15-400mm/s.
● Recommended fluids: Any of the hydraulic fluids listed below can be used.
Petroleum base oil: Use oil equivalent to ISO VG32 or VG46.
Synthetic solution: use a phosphate ester solution or a polyol ester solution. When using a phosphate ester solution, seal it with a special fluoro rubber.
Aqueous solution: use water glycol solution.
● Working oil temperature: The continuous working temperature is -15 to 70 °C.
● Pollution control :Pay attention to controlling the pollution of hydraulic fluid, otherwise it will cause damage to the valve or shorten the service life.
Please ensure that the pollution degree is NAS 1638-12, with 25 u m or more precision pipeline oil filter.

Ordering Code:

CPRV-M 02 1

1 2 3 4

1

Serie

CPRV

2

Piping method

Blank :Line type

M:Manifold

3

Model

02

4

Pressure range (kgf/cm2)

1: 5-30

2: 10-50

3: 20-120

4: 30-240

5: 50-380

Hydraulic Control Valve , Hydraulic Pressure Reducing Valve Pascal Type
