Pneumatic Sequence Valve Compact Structure Max Operating Pressure 0.6 Mpa
Pneumatic Sequence Valve Compact Structure Max Operating Pressure 0.6 Mpa
Pneumatic Sequence Valve Compact Structure Max Operating Pressure 0.6 Mpa
Pneumatic Sequence Valve Compact Structure Max Operating Pressure 0.6 Mpa
Specifications
Brand Name :
Jiayan
Model Number :
CWD-B
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PayPal
Supply Ability :
500 sets per week
Delivery Time :
7 days
Packaging Details :
Poly bag and carton box
Material :
Carbon Steel
Max. Operating Pressure :
0.6 Mpa
Min. Operating Pressure :
0.2 Mpa
Withstanding Pressure :
1.5 Mpa
Delayed Time :
1 ~ 10
Min.Passage Area :
4.0 mm2
Operating Temperature :
0 ~ 70 °C
Usable Fluid :
Dry air
Weight :
0.2 kgs
Warranty :
1 year (change new one for free)
Description

Pneumatic Sequence Valve Compact Structure Long Life Expectancy Max. Operating Pressure 0.6 Mpa

Note:

1. The delay time during initial operation may be extended by the placement time.
2. The air tank can be added using the T port to increase the capacity and thus extend the

delay time.
3. If the secondary side actuator is still not operating when the set delay time is exceeded,

the primary side supply air pressure must be reduced to zero before the confirmation

operation.

4.When confirming the delay time, tighten the fixing nut of the delay time adjusting bolt first

and then confirm again

Pneumatic Sequence Valve Compact Structure Max Operating Pressure 0.6 Mpa

Attention:


The actual delay time varies with circuit conditions.
Do not over-tighten or loosen the lag time adjusting bolts.
Otherwise, the product may be damaged.
