Adjustable Hydraulic Control Valve / 12 Volt Hydraulic Sequence Control Valves Check Valve
Adjustable Hydraulic Control Valve / 12 Volt Hydraulic Sequence Control Valves Check Valve
Adjustable Hydraulic Control Valve / 12 Volt Hydraulic Sequence Control Valves Check Valve
Adjustable Hydraulic Control Valve / 12 Volt Hydraulic Sequence Control Valves Check Valve
Specifications
Brand Name :
Jiayan
Model Number :
CLH
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, PayPal
Supply Ability :
400 sets per week
Delivery Time :
7 days
Packaging Details :
poly bag and carton box
Material :
Carbon Steel
Adjustable Pressure Range :
5.0~18.0 MPa
Operating pressure range :
6.0~35.0 MPa
Starting Pressure :
0.01 MPa
Operating temperature °C :
0~70°C
fluid :
hydraulic oil equivalent to ISO-VG-32
Warranty :
1 year (change new one for free)
Description

Hydraulic Sequence Valve High Operation Pressure Simple Installation Carbon Steel Body

SPECIFICATION

Model No.

CLG-3A

CLG-6A

Adjustable pressure range MPa

1.0~6.0

5.0~18.0

Operating pressure range MPa

2.0~35.0

6.0~35.0

Adjustable screw pressure change value MPa/Rev

1.0

2.8

Starting pressure MPa

0.01

Operating temperature °C

0~70°C

Useable fluid

hydraulic oil equivalent to ISO-VG-32

Note:

Excessive side oil supply can sometimes result in inaccurate sequential actions.

Install a flow control valve with a built-in check valve in front of the oil hole or

execute flow control on the oil pressure source.

Ordering Code:

CLG - 3 A(5.0MPa)

1 2 3 4

1

Series

CLG

2 adjustable pressure range

3: 1.0~6.0 MPa

6: 5.0~18.0MPa

3

A

Manifold type

4

Pre-set pressure (Set pressure value for sequence operation)

Provide a difference of more than 1MPa between operating and setting pressure.
When using multiple CLG sequence valves in a parallel fashion, provide each set pressure with a pressure difference more than 1MPa.
