3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
Specifications
Brand Name :
HOTHMI
Model Number :
TFT-H030A8ZCISTKN40
Place of Origin :
dongguan,China
MOQ :
2
Payment Terms :
L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :
99999
Delivery Time :
25 days
Display content :
268x800 dot matrix
Dimensions (mm) :
26.42x79.85x1.7
Field of view window size :
Full View
Backlight brightness :
1000cd/m2
driver chip :
ST7701S
Interface :
RGB +9b_3SPI
Operating Temperature: :
-30°C~80 °C
Description

3.0 inch bar TFT LCD display module/IPS full viewing angle/268x800 dots/RGB+SPI interface/ST7701S/sunlight visible/wide temperature

TFT-H030A8ZCISTKN40 | 3.0" IPS TFT LCD Display | TFT LCD Display Manufacturer | 268x800 resolution | -30℃~80℃ | For Instrumentation | Interface RGB +9b_3SPI | Wide Temperature | IC ST7701S

Introducing our cutting-edge TFT-H030A8ZCISTKN40 3.0 Inch IPS TFT Display Panel, meticulously crafted for precision and performance in instrumentation applications. Elevate your visual experience with a display that seamlessly combines technological excellence with wide temperature adaptability.
Boasting a remarkable 268x800 resolution, every detail comes to life on this vibrant TFT LCD screen. Witness clarity and crispness like never before as your data, graphs, and measurements unfold in stunning precision.
Designed to endure even the most challenging environments, this display panel defies temperature extremes with an impressive operating range of -30℃ to 80℃. Whether you're working in frigid cold or scorching heat, our display maintains its optimal functionality, ensuring reliability and accuracy in critical situations.
Experience seamless communication through the RGB +9b_3SPI interface, providing effortless connectivity that enhances the efficiency of your instrumentation tasks. The inclusion of the advanced ST7701S IC further elevates performance, ensuring smooth operations and rapid data processing.
Immerse yourself in a world of possibilities as this TFT LCD Display Manufacturer empowers your instrumentation endeavors. Unleash the power of technology with a display that doesn't just meet standards; it sets new benchmarks for excellence. Trust in our commitment to quality, precision, and innovation as you equip your instruments with the TFT-H030A8ZCISTKN40 - where cutting-edge meets rugged reliability.

parameter Parameter Description unit
TFT LCD Standard strip TFT
Diagonal inches 3.0” Inch
resolution 268 × RGB × 800 (TFT) dots
Dimensions 26.42x79.85x1.7 mm
Size (AA) area 24.12x72.0 mm
LCD specifications TFT, white, transmissive
Display perspective IPS(U80/D80/L80/R80)
aspect ratio 3:1
Backlight specifications LED, white
TFT driver chip ST7701S
Touch glass type None
surface Anti-glare
Display brightness 1000 cd/㎡
Operating temperature -30~+80 °C
Storage temperature -40~+90 °C

Search keyword: tft 3.0, tft 3.0", 3.0 tft lcd, 3.0" tft 3.0, 3.0 inch tft lcd, tft lcd 3.0, 3.0 tft display, 3.0" tft display, 3.0 inch tft display, tft display 3.0, tft display 3.0", 3.0 lcd module

3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable


3 Inch TFT LCD Display 268x800 RGB Interface Sunlight Readable
TFT-H030A8 V0-0.pdf
