Specifications
Brand Name :
MENSION
Model Number :
S32
Certification :
CE RoHS
Place of Origin :
CN
MOQ :
1 Set
Price :
Contact Us
Payment Terms :
T/T,Western Union,MoneyGram,Paypal
Supply Ability :
1000 Sets Per Month
Delivery Time :
2 - 7 Working Days
Packaging Details :
One Plywood For One Set
Crimping Range :
14 - 87mm
Hose Size :
1/4 - 2.5inch
Die Sets :
13
Color :
Blue
Max. Opening :
31mm
Crimping Force :
650T
Product Name :
S32 Hose Crimper Machine
Application :
Workshop
Warranty :
3 years
Power :
4KW 50Hz
Size :
650*550*1360mm
Weight :
310Kg
Description
S32 Hose Pipe Crimping Machine
Product Overview

The S32 hose crimper is a versatile industrial tool designed for precise crimping of hose fittings from 1/4 inch to 2 inches in diameter. This robust equipment ensures secure connections in hydraulic systems, automotive components, and various industrial applications. Featuring interchangeable dies and adjustable settings, it delivers consistent, reliable performance with user-friendly controls and enhanced safety features.

Main Features
  • Crimping Range: Handles hoses from 1/4 inch to 2 inches diameter for versatile applications
  • Interchangeable Dies: Multiple die sets accommodate different hose sizes and fitting types
  • Adjustable Settings: Precise control over crimping pressure and depth for consistent results
  • Hydraulic Power: Provides substantial force for effective and reliable crimping operations
Technical Specifications
Model S32 Hose Crimper Pressing Machine
Crimping Range 14 - 87 mm
Crimping Force 650 T
Hose Size 1/4 - 2.5 inch
Max. Opening 31 mm
Die Sets 13
Die Set Type P32
System Pressure 31.5 Mpa
Accuracy 0.01 mm
Control MS
Standard Voltage 220 V
Motor Power 3 KW
Length 650 mm
Width 550 mm
Height 1360 mm
Weight 310 KG
Hydraulic AC Hose Crimping Tool Gates P20 Hydraulic Hose Crimper Hose Clamp Crimping Tool
P32 Hose Crimper Die Sets
Die No. Crimping Range Length
6 * 6 ... 8mm 55mm
8 * 8 ... 10mm 55mm
10 * 10 ... 12mm 55mm
12 * 12 ... 14mm 55mm
14 14 ... 16mm 55mm
16 16 ... 19mm 55mm
19 19 ... 22mm 55mm
22 22 ... 26mm 70mm
26 26 ... 30mm 70mm
30 30 ... 34mm 70mm
34 34 ... 39mm 75mm
39 39 ... 45mm 75mm
45 45 ... 51mm 90mm
51 51 ... 57mm 90mm
57 57 ... 63mm 100mm
63 63 ... 69mm 110mm
69 69 ... 74mm 110mm
74 * 74 ... 78mm 110mm
78 * 78 ... 87mm 110mm
Note:
• "*" indicates non-standard die sets
• Customized die sets are available
• Special voltages 110V, 208V, 240V, 415V are available
Optional Features
  • UC control system
  • Position limit device
Crimping Applications

The P32 hydraulic hose crimping machine is designed for various industrial applications including hydraulic systems, automotive components, and manufacturing processes requiring secure hose connections.
