Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Specifications
Brand Name :
MENSION
Model Number :
MS-P32N
Certification :
CE RoHS
Place of Origin :
CN
MOQ :
1 Set
Price :
Contact Us
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Sets Per Month
Delivery Time :
2 - 7 Working Days
Packaging Details :
One Plywood For One Set
Crimping Range :
14 - 87mm
Hose Size :
1/4 - 2.5inch
Die Sets :
13
Color :
Blue
Max. Opening :
31mm
Crimping Force :
650T
System Pressure :
31.5Mpa
Voltage :
380V
Size :
650*550*1360mm
Weight :
310Kg
Description
P32N Numerical Control Hose Crimping Machine
The P32N hose crimper is a Finn Power type numerical control hose crimping machine that automates the crimping process with precision. Utilizing advanced numerical control technology, it delivers accurate and consistent crimps while eliminating variations to ensure reliable hydraulic connections.
Key Features
  • High precision crimping with 0.01mm accuracy
  • High efficiency for mass hose production
  • Easy to operate with user-friendly controls
  • Quick mold change capability
  • Integrated safety features for operator protection
  • Versatile handling of various hose sizes and configurations
Technical Specifications
Model P32N Hose Pressing Machine
Crimping Range 14 - 87 (mm)
Crimping Force 650 (T)
Hose Size 1/4 - 2.5 (inch)
Max. Opening 31 (mm)
Die Sets 13
Die Set Type P32
System Pressure 31.5 (Mpa)
Accuracy 0.01 (mm)
Control UC
Standard Voltage 380 (V)
Motor Power 3.75 (KW)
Dimensions (L*W*H) 650 * 550 * 1360 (mm)
Weight 310 (KG)
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
P32 Crimper Die Sets
Die No. Crimping Range Length
6* 6 - 8mm 55
8* 8 - 10mm 55
10* 10 - 12mm 55
12* 12 - 14mm 55
14 14 - 16mm 55
16 16 - 19mm 55
19 19 - 22mm 55
22 22 - 26mm 70
26 26 - 30mm 70
30 30 - 34mm 70
34 34 - 39mm 75
39 39 - 45mm 75
45 45 - 51mm 90
51 51 - 57mm 90
57 57 - 63mm 100
63 63 - 69mm 110
69 69 - 78mm 110
* Non-standard die sets
Customized die sets available
Special voltages available: 110V, 208V, 240V, 415V
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
Industry Applications
Hose crimping machines are essential tools across multiple industries where secure and reliable hose connections are critical for fluid transfer systems.
Primary Application Fields
  • Manufacturing & Industrial: Automotive, aerospace, machinery, and equipment production for hydraulic systems, pneumatic systems, and fluid transfer applications
  • Construction & Infrastructure: Concrete pumping, foundation work, tunneling, and heavy-duty construction equipment requiring secure fluid connections
  • Agriculture & Farming: Irrigation systems, sprayers, fertilizers, and farming equipment for efficient fluid distribution
  • Oil & Gas: Drilling operations, offshore platforms, oil refineries, and pipelines in demanding petroleum applications
  • Transportation & Automotive: Vehicle fuel lines, brake systems, and fluid-carrying applications in cars, trucks, buses, and specialized vehicles
  • Marine & Shipbuilding: Shipbuilding, offshore vessels, and maritime equipment for hydraulic systems, fuel lines, and cooling systems
Hydraulic AC Hose Crimper 2 Inch Hydraulic Hose Crimping Machine
