Key Selling Points

• Easy Installation & Centralized Management:Simple to install and operate, ideal for home and residential energy storage scenarios without complicated procedures.
  Stable Specification & High Capacity:51.2V 200Ah with large capacity, steady discharge and strong load-bearing capability, satisfying family daily energy storage and backup requirements.
  Intelligent BMS Full Protection:Built-in high-precision BMS offers protection against overcharge, over-discharge, over-current, short-circuit and over-temperature, prolonging service life and ensuring safe operation.
  Easy Parallel Expansion:Supports parallel connection of multiple batteries with automatic addressing, enabling flexible capacity expansion for future needs.
  Wide Compatibility & Maintenance-Free:Works well with household UPS and PV inverters; maintenance-free design saves families time and labor costs.


• Model	CH—GBP51.2-200R
  Nominal Voltage (V)	51.2
  Cell Specification	100
  Nominal Capacity (Ah)	200
  Nominal Energy (kWh)	10.24
  Operating Voltage Range (V)	44.8~58.4
  Recommended Charging Voltage (V)	55.2
  Recommended Discharge Cut-off Voltage (V)	48
  Standard Charge/Discharge Current (A)	0.5C
  Maximum Continuous Charge/Discharge Current (A)	1C (Customizable)
  Operating Temperature (°C)	-30~ 60 (Recommend 10~ 35)
  Allowable Humidity Range(%RH)	<85
  Storage Temperature(°C)	-20~65(Recommend 10~ 35)
  Charging Temperature(°C)	0~55
  Discharging Temperature(°C)	-10~55
  Protection Level	IP20
  Cooling Method	Natural Air Cooling / Intelligent Fan
  Cycle Life	5000+Times at 80% DOD
  Maximum Dimension(D*W*H)mm	682*510*246
  Weight(kg)	96
  Note: The above data is for reference only. In case of any changes, no further notice will be given.
