| Product Name | Fuel Transport Tank Semi Trailer |
| Overall dimensions | 10400×2500×3800(mm) |
| GVW | 35000Kg |
| Total net weight | 5200Kg |
| Loading capacity | 29800Kg |
| Tank capacity( CBM ) | 30000L to 60000L |
| Medium | Fuel Such As: Gasoline, Kerosene, Diesel and Jet Fuel |
| Tank body thickness(mm) | Stainless Steel 5182 5mm steel |
| End plate | Stainless Steel 5182 6mm steel |
| Compartment | 2-6 As Customer Need |
| Chassis brand | HUATE |
| Approach/departure angle | /19° |
| Tire specification | 11.00R20 12PR,12R22.5 12PR |
| Transmission | Manual |
| Axle Number | 2 |
| Axle Brand | BPW/FUWA/ZY/ L1/HO’S/ SAF/ PDME,13ton Axle |
| Manhole covers | 500mm manhole cover .3 sets with 3 breather valve. |
| Discharge Valve | 4’change into 3’ |
| Dischage Pipe | 4’seamless steel tube |
| Discharge Valve Vox | Totally-enclosed |
| Spill Discharges | 1at the rear |
| Bottom Valve | 1 Set |
| Rear Ladder | Dismountable |
| Walkway | On the top |
| Top Ladder | Standard |
| Pedal | Anti-Skid Pedal |
| Color and Logo | As Customer Need |
| Standard Configuration | Chassis,Arc-shaped Body,Sub Frame,Rear Lifting Part,Loading Bunker,Pushing-out Plate,Sewage Tank,Climbing Ladder |
| Selective Configuration | Multifunctional Rear Lifting Part,Rear Handrail and Footplate,Other shapes of body etc. |
