Specifications

Place of Origin :

Hubei, China

Brand Name :

HUATE

Price :

$9,400/pieces 1-9 pieces

Use :

Truck Trailer

Type :

Semi-Trailer

Material :

Stainless Steel, Stainless Steel

Size :

10400*2500*3800(mm), 10400*2500*3800(mm)

Max Payload :

25001-30000 kg

Product name :

Fuel Tank Semi Trailer

Stroage :

Fuel ,Such as: Gasoline, Kerosene, Diesel and Jet fuel

Axle :

Tire Specification :

11.00R20 12PR,12R22.5 12PR

Loading capacity :

29800Kg

Color :

Customer's Request

MOQ :

Packaging Details :

Wooden box

Delivery Time :

Payment Terms :

T/T

Supply Ability :

Meet large-scale orders

Certification :

CCC

Description

Stainless Steel 2 Axles Liquid Storage Semi Trailer - 29800Kg Loading Capacity

Premium Fuel Transport Solution

Our 2 Axles Stainless Steel Liquid Storage Semi Trailer is designed for safe and efficient transportation of petroleum derivatives including gasoline, diesel, crude oil, and lubricating oil. Ideal for oil depots, gas stations, oil fields, and chemical plants.

Key Features

Multi-channel reinforced anti-wave baffle plate design reduces fuel impact
Combined tank opening with self-locking cover and breathing valve system
Electrostatic grounding wire for enhanced safety
Built-in fuel pump system for self-priming and self-draining capability
Dual pumping pipes and suction lift included
Comes with two fire extinguishers for emergency situations
Available in aluminum, carbon steel, or stainless steel construction

Technical Specifications

Product Name	Fuel Transport Tank Semi Trailer
Overall dimensions	10400×2500×3800(mm)
GVW	35000Kg
Total net weight	5200Kg
Loading capacity	29800Kg
Tank capacity	30000L to 60000L
Medium	Fuel (Gasoline, Kerosene, Diesel, Jet Fuel)
Tank body thickness	Stainless Steel 5182 5mm steel
End plate	Stainless Steel 5182 6mm steel
Compartment	2-6 (Customizable)
Chassis brand	HUATE
Tire specification	11.00R20 12PR,12R22.5 12PR
Axle Number	2
Axle Brand	BPW/FUWA/ZY/L1/HO'S/SAF/PDME,13ton Axle

Additional Features

500mm manhole cover with 3 sets of breather valves
4' discharge valve with seamless steel tube
Totally-enclosed discharge valve box
Rear spill discharge and bottom valve
Dismountable rear ladder and top walkway
Anti-skid pedal for safety
Customizable colors and logos

Standard Configuration

Chassis, Arc-shaped Body, Sub Frame, Rear Lifting Part, Loading Bunker, Pushing-out Plate, Sewage Tank, Climbing Ladder

Optional Features

Multifunctional Rear Lifting Part, Rear Handrail and Footplate, Custom body shapes
