Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Class A 1 2 Inch Galvanized Steel Cable For Galvanized Barrier Cable
Specifications
Place of Origin :
Anhui,China
Brand Name :
Litong Global
Certification :
ISO9001 and other 3rd party Inspection report
Model Number :
lt-160221
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
In Coil or on Drum
Delivery Time :
10 days after confirmed order
Payment Terms :
TT/LC
Supply Ability :
400tons/day
Steel Grade :
Middle and High Carbon Wire Rod
Wire Gauge :
1.0-4.8mm
Type :
Galvanized
Application :
Rope
Alloy Or Not :
Non-alloy
Special Use :
Free Cutting Steel
Standard :
AISI|ASTM|BS|DIN|GB|JIS
Description

Extra-High Strength Galvanized Steel Wire

Dia. Range(mm)

Tensile(Mpa)

Stress at 1% Elongation(Mpa)

Zinc coating(g/m2)

Packing Size

Weight/Package

1.58-2.0

1310-1450

1170-1350

200-210

Coil

1000 meter/Spool-3000meter/Coil

2.0-3.05

1280-1410

1140-1280

200-220

Coil

3.05-3.6

1280-1410

1100-1240

220-270

Coil

3.6-4.0

1280-1410

1100-1240

270-300

Coil

ASTM B 498 Class A; Class B; ASTM A 475 Class A; Class B; Class C; JIS G 3537; ASTM B 957

ISO9001

Grade

Dia.

(mm)

Tensile Strength

Not less

(Mpa)

Stress at elongation of 1%

Not less

(Mpa)

Elongation

L0=250mm

Not less

Torsion

Not less

Times/360°

Mandrel

Dia
≥1.24-2.25 1340 1170 3.0 16 1

Normal

 ≥2.25-2.75 1310 1140 3.0 16 1
≥2.75-3.00 1310 1140 3.5 16 1
≥3.00-3.50 1290 1100 3.5 14 1
≥3.5-4.25 1290 1100 4.0 12 1
≥4.25-4.75 1290 1100 4.0 12 1
≥4.75-5.5 1290 1100 4.0 12 1

High

 ≥1.24-2.25 1450 1310 2.5 16 1
≥2.25-2.75 1410 1280 2.5 16 1
≥2.75-3.00 1410 1280 3.0 16 1
≥3.00-3.50 1410 1280 3.0 14 1
≥3.5-4.25 1380 1240 3.0 12 1
≥4.25-4.75 1380 1170 3.0 12 1
≥4.75-5.5 1380 1170 3.0 12 1

Extra-

High

 ≥1.24-2.25 1620 1450 2.0 14 1
≥2.25-2.75 1590 1410 2.0 14 1
≥2.75-3.00 1590 1410 2.5 12 1
≥3.00-3.50 1550 1380 2.5 12 1
≥3.5-4.25 1520 1340 2.5 10 1
≥4.25-4.75 1520 1340 2.5 10 1
≥4.75-5.5 1520 1270 2.5 10 1

Quality Control:

Total quality control. Every pieces of the raw material; semi-finished products and finished products are tested and recorded in file. The tracking record is used from final products to the very first beginning raw material steel factories.

Third Part like SGS is available for test control before shipment

Sales Territory:

South America; North America; South Korea; Australia, Europe; Middle East; etc
