4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss
4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss
4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss
4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss
Specifications
Model Number :
921020053
Channel Wavelengths :
1295.56, 1300.05, 1304.58, 1309.14 nm
Insertion Loss :
≤ 1.4 dB
Transmission Loss :
≤ 0.5 dB
Reflection Loss :
≤ 0.3 dB
Description

4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss

1. Product Overview

Gracyfiber manufactures high-performance 4-channel LAN-WDM (Local Area Network Wavelength Division Multiplexing) modules designed for 100G/200G high-speed optical communication and 5G fronthaul networks.

4 Channel LAN WDM Module O Band LWDM Mux Demux 1295.56 1300.05 1304.58 1309.14nm FC UPC Low Loss
2. Product Features
  • 4-Channel LAN-WDM Design: 1295.56, 1300.05, 1304.58, 1309.14 nm
  • Extremely Low Module Insertion Loss: Room Temperature Single-Channel IL ≤ 1.4 dB
  • High-Quality Core Components: Transmission T ≤ 0.5 dB, Reflection R ≤ 0.3 dB
  • Customized Pigtails for Specific Processes: 0.9mm Loose Tube (External fiber outlet tube length 1m, total internal bare fiber length >1.5m)
  • Full-Port Connector: FC/UPC High-Standard Connector
  • Rugged Housing Design: 120×80×18 mm High-Stability ABS Plastic Enclosure
3. Applications
  • 100G/200G High-speed optical communication system integration
  • Large-scale deployment and channel expansion of 5G fronthaul networks
  • Interconnection of high-density local area networks (LANs) and metropolitan area networks (MANs) backbone nodes
  • Data center interconnect (DCI) and high-speed transmission network for cloud computing
  • Multi-band hybrid optical communication transmission system
