4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
Specifications
Channel count :
4
Wavelength range :
1295.56 nm - 1309.14 nm
Insertion loss :
≤1.4 dB
Dimensions :
120×80×18 mm
Description
4CH O Band LWDM Module LAN WDM Multiplexer Demultiplexer 1295.56 1300.05 1304.58 1309.14nm Low Loss FC UPC
1. Product Overview

This product is a 4-channel LAN-WDM wavelength division multiplexer, operating at wavelengths of 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm.



2. Core Product Features
4-Channel LAN-WDM Wavelength Design

Supports four LAN-WDM wavelengths: 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm, enabling multiplexed transmission of multiple optical signals.

Low Insertion Loss Performance

The single-channel insertion loss IL at room temperature is ≤1.4 dB, helping to reduce link power loss and improve system transmission efficiency.

Superior Device Performance

Utilizes conventional wavelength division multiplexing devices, with a single device transmission loss T ≤0.5 dB and reflection loss R ≤0.3 dB, ensuring stable and reliable overall optical performance of the module.

Engineered Fiber Outlet Design

The module uses a 0.9 mm loose tube with a 1 m fiber outlet length. Internal components have fiber lengths greater than 1.5 m, facilitating module assembly, wiring, and maintenance.

Reliable Packaging and Connection Configuration

The module is packaged in a 120×80×18 mm ABS plastic box with an FC/UPC connector. Its compact structure and good protection make it suitable for integrated applications in optical communication equipment.



3. Applications
  • LAN-WDM Multi-Wavelength Multiplexing Systems
  • 100G/400G High-Speed ​​Optical Communication Modules
  • High-Speed ​​Optical Interconnects for Data Centers
  • Multi-Wavelength Optical Signal Multiplexing and Demultiplexing Systems
  • Metropolitan Area Networks, Access Networks, and Short-Distance Optical Transmission Networks
  • Integration of Optical Transmission Equipment, Test Platforms, and Passive Wavelength Division Multiplexing Devices
