Specifications
Model NO. :
T-400
Sealing Technology :
Patented O Sealing Technology
Design Base Environment :
45 Degree C
Durability Range :
The Highest Level
Maintenance :
Lower The Cost of Maintance
Transport Package :
Carton Filled with Paper Honeycomb
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8418692090
Supply Ability :
300 Sets Per Month
Service :
OEM
Installation :
Front, Roof, Under Mounting Type
Electric :
Optional Electric Standby System
Colour :
White
Fan Material :
Aluminium Alloy
Condensor Design :
Latest Exclusively for Refrigeration Unit
Customization :
Available | Customized Request
Description

Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System
Top Type Van Refrigerator Unit Reefer Unit with Optional Electric Standby System


Specifications
Introduce:
Suitable for light and medium truck trucks, driven by engine or driven by standby electric refrigeration system, and optional installation of standby electric refrigeration system DC220V/DC380V.

It is the first choice for transporting refrigerated frozen food, dairy products, vegetables, fruits, ice cream and fresh industrial electronic products. Its refrigeration performance is very stable and reliable. SNOWFALL recommends you choose between a classic engine drive unit and a brand new backup built-in unit. Covering all container volumes, one or more of this series will meet your needs.The SF-400, a transport refrigerating unit driven by the engine, is a reliable refrigerating unit for the refrigerating keeping fresh car with the size of 14~-18m of the heat preservation compartment, and also has the selection of bottom hanging condenser inside.

Features
  1. Optional DC 12V or 24V for you to choose, and backup electric refrigeration system DC220V/DC380V optional installation.
  2. The whole transport refrigerating unit is light and compact, the condenser is in front, and the evaporator can be installed as required.
  3. This series of models fully covers the refrigerated capacity ranging from 14 m to 45 m and accurately matches its refrigerated volume from per square meter.
  4. Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Model SF-T400
Applicable Temperature (ºC) +20~ -18


Cooling Capacity		 Environmental Temperature 35°C
0°C 3900
-18°C 2300

Compressor		 Model QP16
Displacement(cc/r) 163 cc



Condenser		 Type P.F.
Fan Type Axial fan
Number of Fan 2 Fan x 1000m3/h
Voltage DC 12V/DC24V



Evaporator		 Type Inner screw tube and aluminium fin
Fan Type Axial fan
Number of Fan 2Fans x 800m3/h
Voltage DC 12V/DC24V

Power Consumption		 ≤ 33A (DC12V)
≤ 16.5A (DC24V)
Refrigerant R-134a/ R-404a
Defrost Type Automatically hot air defrost
Structure Split direct drive unit

Dimensions (mm) /Net weight(kg)		 T400Evaporator 1270x580x170 31.63kg
T 400Condenser 1280x640 x1200 31.91kg
