Specifications
Brand Name :
YUHONG
Model Number :
Extruded Fin tube , Aluminum Extruded Fin tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Base Tube Material Grade :
TP304
Base Tube Material Standard :
ASME SA269 , ASTM A269
Type :
Straight Tube , U bend Tube , Coil Tube
Application :
Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type :
Extruded Fin tube , Aluminum Extruded Fin tube , Fin tube
Fin Material :
Aluminum ,Copper, Stainless Steel, Carbon Steel
Description
ASTM A269 TP304 Extruded Fin Tube Steel For Boilers / Heat Exchangers
Product Specifications
Attribute Value
Base Tube Material Grade TP304
Base Tube Material Standard ASME SA269, ASTM A269
Type Straight Tube, U bend Tube, Coil Tube
Application Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type Extruded Fin tube, Aluminum Extruded Fin tube, Fin tube
Fin Material Aluminum, Copper, Stainless Steel, Carbon Steel
Product Description

The ASTM A269 TP304 Extruded Fin Tube is a high-efficiency heat transfer component made from austenitic stainless steel. The TP304 grade offers excellent corrosion resistance and mechanical properties, while the extruded fin design significantly enhances heat transfer surface area for demanding applications.

The integrally formed extruded fin design creates a strong bond with the tube material, maximizing heat transfer efficiency. This construction provides high resistance to oxidation and thermal stress, making it ideal for high-temperature environments.

Chemical Composition
Grade C Ni Mn Si P S
TP304 0.08% max 8.0-11.0% 2.0% max 1.0% max 0.045% max 0.030% max
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness
TP304 ≥ 515 MPa (75 ksi) ≥ 205 MPa (30 ksi) ≥ 35% in 50 mm Typically ≤ 90 HRB
Key Applications
  • Power Generation: Essential for heat exchangers in steam generation and cooling systems, improving plant efficiency. Used in boiler economizers for waste heat recovery and feedwater preheating.
  • Chemical Processing: Ideal for handling corrosive fluids at high temperatures in heat exchangers and reactors, ensuring process efficiency and safety.
  • HVAC Systems: Maximizes heat exchange in condenser and evaporator coils for air conditioning and refrigeration units, enhancing energy efficiency.
  • Oil and Gas Industry: Provides reliable performance in offshore platforms and refineries, withstanding corrosive environments and mechanical stress.
