Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Bulk SA249 TP304 Aluminum Fin And Tube Heat Exchangers Extrusions
Specifications
Brand Name :
YUHONG
Model Number :
Extruded Fin tube , Aluminum Extruded Fin tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Base Tube Material Grade :
TP304
Base Tube Material Standard :
ASTM A249, ASME SA249
Type :
Straight Tube , U Bend Tube , Coil Tube
Application :
Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type :
Extruded Fin tube , Aluminum Extruded Fin tube , Fin tube
Fin Material :
Aluminum , Copper , Stainless Steel , Carbon Steel
Description
Extruded Fin Tube, ASME SA249 TP304 Finned Tube For Heat Exchanger, Air Cooler
Product Specifications
Attribute Value
Base Tube Material Grade TP304
Base Tube Material Standard ASTM A249, ASME SA249
Type Straight Tube, U Bend Tube, Coil Tube
Application Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type Extruded Fin tube, Aluminum Extruded Fin tube, Fin tube
Fin Material Aluminum, Copper, Stainless Steel, Carbon Steel
Product Description
ASME SA249 TP304 is a specification for welded austenitic steel boiler, superheater, heat-exchanger, and condenser tubes. TP304 refers to the grade of stainless steel used in the tubes.
Finned Tubes are tubes that have fins attached to their outer surface. These fins increase the surface area of the tube, allowing for better heat transfer between the fluid inside the tube and the surrounding environment.
A finned tube heat exchanger is a type of heat exchanger that uses finned tubes to transfer heat between two fluids. One fluid flows inside the tubes, while the other fluid flows over the fins on the outside of the tubes. This design maximizes the heat transfer efficiency of the exchanger.
The ASME SA249 TP304 finned tubes for heat exchangers are specifically designed and manufactured to meet the requirements of the ASME SA249 specification. They are made from TP304 stainless steel, which is known for its excellent corrosion resistance and high-temperature strength.
Detailed Specifications
Specification: ASME SA249 Grade: TP304
Application: Oil Cooler, Pre Heater, Radiator, Air Conditioner Evaporator Type: Extruded
Fin Grade: Al 1060 Shape: Round
Chemical Composition
Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
304 8000 193 17.2 16.2 500 720
Applications
Air-cooled heat exchangers: These finned tubes are used in air-cooled heat exchangers to transfer heat from hot process fluids to the surrounding air. The fins on the tubes increase the surface area, allowing for efficient heat transfer.
Shell and tube heat exchangers: SA249 TP304 finned tubes are also used in shell and tube heat exchangers, where they are placed inside a shell and fluid flows through the tubes.
Condensers: Finned tubes are commonly used in condensers, where they help in the condensation of vapors by transferring heat from the vapor to the surrounding cooling medium.
Radiators: Radiators in various industrial and automotive applications also use finned tubes to dissipate heat efficiently.
