Specifications
Brand Name :
YUHONG
Model Number :
Low Fin Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Base Tube Material Grade :
ASTM A179, ASME SA179
Base Tube Material Standard :
A179
Type :
Straight Tube, U Tube
Application :
Heat Exchanger, Condenser
Fin type :
Carbon Steel,Stainless Steel,Copper Alloy,Alloy Steel
Fin Material :
Aluminum , Copper , Stainless Steel , Carbon Steel
Description
Low Fin Tube ASTM A179 Heat Exchanger
Product Specifications
Attribute Value
Base Tube Material Grade ASTM A179, ASME SA179
Base Tube Material Standard A179
Type Straight Tube, U Tube
Application Heat Exchanger, Condenser
Fin type Carbon Steel, Stainless Steel, Copper Alloy, Alloy Steel
Fin Material Aluminum, Copper, Stainless Steel, Carbon Steel
Product Description

Low fin tubes with a base tube made of ASTM A179 are highly efficient and durable components for heat exchangers, condensers, and evaporators. Their enhanced heat transfer properties, combined with the durability and integrity of ASTM A179 low-carbon steel, make them ideal for various industrial applications.

These low fin tubes provide a compact, cost-effective, and reliable solution for improving heat transfer efficiency in demanding environments.

Key Features
High Heat Transfer Efficiency
Durable ASTM A179 Material
Integral Fin Construction
Compact Design
Anti-Corrosion
Anti-Wear
High Stability
Anti-Fouling
Lower Contact Resistance
Technical Specifications
Parameter Value
Tube OD 12.7~31.75 (mm)
Tube Wall Thickness 1.65~3.0 (mm)
Tube Length ≤18,500 (mm)
Fin Thickness 0.3~0.5 (mm)
Fin Height 0.9~1.3 (mm)
Fin Pitch 16~30 FPI
Fin Type LowFin
Tube Material C.S., S.S., A.S., CopperAlloy
Chemical Composition
Material Grade C Si Mn P S
A179 0.06-0.18 ≤ 0.25 0.27-0.63 ≤0.035 ≤0.035
Mechanical Properties
Property Value
Tensile Strength (MPa) ≥325
Yield Strength (MPa) ≥180
Elongation (%) ≥35
Hardness, HRB ≤72
Applications
  • Oil Refinery
  • Petrochemical Plants
  • Condensers and Heat Exchangers
  • Evaporator for Power Plants
  • Power Generation
  • Air Conditioning
  • Refrigeration Manufacturing
  • Sea Water Desalination
  • Pharmaceutical Equipment
  • Pulp and Paper Industry
