Specifications
Brand Name :
YUHONG
Model Number :
Low Fin Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Bast Tube Material Grade :
UNS C70600 O61 , Cu-Ni 90/10
Bast Tube Material Standard :
ASTM B111 , ASME SB111
Type :
Straight Tube
Application :
Heat Exchangers, Condensers, Coolers, Etc.
Fin type :
Low Fin
Fin Material :
Copper
Description
Low Fin Tube ASME SB111 C70600 Copper Nickel Alloy Base Tube
Product Specifications
Base Tube Material Grade UNS C70600 O61, Cu-Ni 90/10
Base Tube Material Standard ASTM B111, ASME SB111
Type Straight Tube
Application Heat Exchangers, Condensers, Coolers, Etc.
Fin Type Low Fin
Fin Material Copper
Product Description
Low fin tubes are heat exchanger tubes featuring short, integral fins on the outer surface. These fins are formed directly from the tube material, increasing surface area for heat transfer while maintaining structural integrity. Ideal for applications requiring enhanced heat transfer without significantly increasing tube diameter.
The ASME SB111 UNS C70600 O61 Copper-Nickel alloy offers excellent corrosion resistance to seawater and good fabricability. The 90/10 copper-nickel composition (90% copper, 10% nickel) provides strength, corrosion resistance, and ductility, making it suitable for marine, automotive, shipping, offshore, and power generation applications.
Low fin tubes provide superior heat transfer performance compared to plain tubes while maintaining the same diameter as the base tube, allowing use in standard shell and tube baffles and tube sheets.
Technical Specifications
Equivalent Grades
STANDARD WERKSTOFF NR. UNS
Cu-Ni 90/10 2.0872 C70600
Grade Types
Type UNS EN GB ISO JIS
Copper C12200 CW024A TP2 Cu-DHP C1220
Copper C12000 CW023A TP Cu-DLP C1201
Admiralty Brass C44300 CW706R HSn70-1 CuZn28Sn1As C4430
Admiralty Brass C68700 CW702R HAI77-2 CuZn20AI2Ass C6870
Copper Nickel 90/10 C70600 CW352H BFe10-1-1 CuNi10Fe1Mn C7060
Copper Nickel70/30 C71500 CW354H BFe30-1-1 CuNi30Mn1Fe C7150
Chemical Composition
Cu Mn Pb Fe Zn Ni
88.6 min 1.0 max 0.05 max 1.8 max 1 max 9-11 max
Mechanical Properties
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
0.323 lb/in³ at 68°F 2100°F 38 15 30%
Applications
Process Heaters
Waste Heat Boilers
Petrochemical Industries
Refinery Plant
Waste Heat Recovery Systems
Heating Equipment
Economizers
Heat Exchangers
Oil Coolers
Evaporators
Chillers
