BTB Connector 0.8mm Pitch Dual Slot SMT SMD Female Male PCB Board-to-Board Connector



Product Highlights


✅ Blind Mating & Self-Alignment Anti-Misalignment Design: Built-in guide ribs & anti-keying structure absorb PCB assembly tolerance, avoiding pin damage during manual/automated mating. ✅ High-Speed Signal Integrity: Optimized contact geometry for stable high-speed data transmission, low crosstalk for high-density PCB stacking.

✅ Multiple Mated Height Options: Standard stacking heights available, flexible for multi-layer PCB modular design.

✅ Dual Slot SMT Structure: Male & female SMD surface mount, compatible with standard PCB reflow process.



Product Description

Category Parameter Details
Electrical Pitch 0.8 mm

Rated Current 0.5 A per contact

Rated Voltage 50 V AC/DC

Contact Resistance ≤ 25 mΩ (initial)

Insulation Resistance ≥ 10 GΩ

Withstand Voltage 250 V AC, 1 min
Mechanical Mating Cycles 500 cycles minimum

Mating Tolerance XY self-alignment tolerance for blind mating

Mount Type SMT / SMD Surface Mount

Structure Dual Slot, Male + Female set
Material & Plating Housing LCP, UL94V-0, high-temperature resistant

Contact Material Copper Alloy

Contact Plating Gold plating on contact area; Nickel underplate

Termination Plating Matte Tin over Nickel
Environment Operating Temp -40°C ~ +105°C

Compliance RoHS, REACH, Halogen-free optional
Soldering Guide Reflow Profile Lead-free reflow, peak temp ≤260°C, comply with IPC/JEDEC J-STD-020

Cross‑Reference / Alternative

Pin-to-pin footprint compatible alternative for JAE KX14/KX15 series, Hirose FX18 series, Molex 0.8mm pitch BTB dual slot series.

Note: Verify stack height & pin count before PCB layout; provide datasheet & 3D STEP for your CAD check.

BTB Connector 0.8mm Pitch Dual Slot SMT SMD Female Male PCB Board to Board Connector

BTB Connector 0.8mm Pitch Dual Slot SMT SMD Female Male PCB Board to Board ConnectorBTB Connector 0.8mm Pitch Dual Slot SMT SMD Female Male PCB Board to Board ConnectorBTB Connector 0.8mm Pitch Dual Slot SMT SMD Female Male PCB Board to Board Connector


Product Feature

  1. Dual-slot guide structure prevents reverse insertion, supports blind mating & self-alignment, reduces assembly scrap.
  2. High-temperature LCP insulator, stable during lead-free reflow soldering, no warpage.
  3. Precision copper alloy contact with gold plating, stable impedance, low contact resistance for high-speed signals.
  4. SMD tape & reel packaging, directly compatible with SMT pick & place machines.
  5. Flexible pin count & mated height customization for modular PCB stacking.
