0.8mm Pitch BTB Connector 40 100 Pin High Transmission Speed Male Female Connector



Product Highlights

✅ Blind Mating & Self-Alignment Anti-Misinsertion Design: Built-in guiding structure with X/Y axis tolerance absorption, reduces mating damage risk during manual & automated assembly, prevents reverse insertion.

✅ High-Speed Signal Integrity: Optimized terminal impedance design, stable high-speed transmission for high-frequency signal paths.

✅ Controllable Mated Height: Multiple stacked mating height options to match your PCB gap requirement; compact 0.8mm pitch saves PCB layout space.

✅ SMT Reel Packaging: Ready for automatic pick & place, compatible with standard SMT assembly lines.



Product Description

Category Item Specification
Electrical Performance Pitch 0.8 mm

Pin Count 10 / 20 / 40 / 100 Pin

Rated Current 1.0 A per pin

Rated Voltage 60 V DC

Contact Resistance ≤30 mΩ

Insulation Resistance ≥500 MΩ @500V DC

Dielectric Withstanding Voltage 500V AC, no breakdown for 1 min
Mechanical Performance Mating Cycles Min 50 cycles

Mating / Unmating Force Low insertion force, stable retention force

Self-alignment Tolerance X/Y directional offset tolerance for blind mating
Material & Plating Housing High-temperature LCP, UL94 V-0

Contact Material Phosphor Bronze Copper Alloy

Contact Area Plating Gold plating (custom gold thickness available)

Solder Tail Plating Matte Tin over Nickel barrier
Environmental Operating Temp -40℃ ~ +85℃

Compliance RoHS, REACH
Soldering Guide Reflow Profile Lead-free SMT reflow, peak temp ≤260℃, dwell time 30~60s

Cross‑Reference / Alternative

This 0.8mm BTB series is footprint-compatible and electrically interchangeable with mainstream international BTB product lines, a direct drop-in replacement for:

  • Molex SlimStack 0.8mm BTB series
  • Hirose ER8 / BM series
  • JAE DX07 series
  • Samtec high-density mezzanine connectors

Note: Verify 3D drawing and mating height before formal PCB layout; free samples available for validation.
