Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port
Specifications
Brand Name :
MESTECHS
Place of Origin :
CHINA
Model Number :
MSG3208
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200sets/week
Delivery Time :
60 work days
Packaging Details :
Common package
material :
Fiber copper power line
power input :
100-265 AC
configration :
HTTP WEB TELNET
application :
industrial outdoor railway
POE :
PSE Power over Ethernet
networking :
managed
Description

MSG3208 8-port Gigabit managed Ethernet switch POE PSE industrial outdoor 220v AC input

Features

  • 8*100/1000mbps POE port；2*100/1000mbps UP Link port;1*100/1000mbps SFP Port
  • 100m Distance
  • Vlan function
  • Support IEEE802.3AF/AT
  • Whole Power:120W(52V 2.3A)
  • All port supported by MDI/MDIX auto flip and self negotiation
  • Supply 11*10/100/1000Mpbs adaptive high speed forwarding data packet non-lost port.
  • Support IEEE802.3x flow control for Full-duplex mode and backpressure for Half-duplex mode.
  • Each port max. power supply reached 30W.


Application

  • Wireless Access Point
  • IP Camera
  • IP Phone
  • Computer Networks

Specifications

Product 8+2+1 Port full giga POE Switch (Built-in)
Model MSG3208
POE Port 1 to 8 support IEEE802.3AF/AT Standard
Output Power 15.4W/30W IEEE802.3af/at
Power Pin Both 1/2+,3/6- and 4/5+7/8-
Whole Power ≤120W (52V 2.3A)
POE Protocol IEEE 802.3af/IEEE 802.3at
POE Type End-span
Power Distance ≤200m
Network Standard IEEE 802.3, IEEE802.3u,802.3x,802.3af/at
Network Medium

100/1000BASE-TX: 5 class
and above non shielded twisted pair
Data Distance ≤100m
Switch Capability 22Gbps
Forwarding Mode Store and forward
Forwarding Rate

100Mbps:14880pps
1000Mbps:14800pps
MAC Address MAC address table 2K
Port Function

Power priority mechanism, fast and forward,
MAC automatic learning and aging
IEEE802.3X Full-duplex and mode
and backpressure for Half-duplex mode
LED Indicator

Each port occupied 1 LINK/ACT.100Mbps,
POE Status Indicator, Whole power indicator
Working Environment Working temperature:-10°-- 55°C
Input AC110-240V 50/60HZ

Gigabit Managed Industrial Ethernet Switch , Industrial PoE Switch 8 Port

Order Information

Product Description Order Code

8-port Gigabit managed Ethernet switch MSG3208

8-port Gigabit managed POE Ethernet switch MSG3208P
