Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+
Specifications
Brand Name :
MESTECHS
Place of Origin :
CHINA
Model Number :
MSG1008
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200sets/week
Delivery Time :
60 work days
Packaging Details :
Common package
material :
Fiber copper cable
power input :
100-265 AC
application :
industrial outdoor railway
PSE :
36-72V
Description
MSG1008 8-port Gigabit Ethernet switch POE PSE industrial outdoor 220v AC input switch
  • Support 8*10/100/1000Mbps RJ45 Port(Support PoE+).
  • All ports supported by MDI/MDIX auto flip and self-negotiation.
  • The whole power max. is 120W, up to 30W per port.
Network Standard

IEEE802.3/IEE802.3u/IEE802.3ab/IEE802.3z/IEE802.1d/IEE802.1w/

IEE802.1s/IEE802.1Q/IEE802.1p/IEE802.3x/IEE802.3af/IEE802.3at
Port 8*10/100/1000Mbps RJ45 Port
PoE Power

8*10/100/1000Mbps RJ45 Port(Support PoE+)

The whole power max. Is 120W

Up to 30W per port
PoE Connection

Support IEEE802.3af/at

Both 1/2+,3/6-and 4/5+,7/8-

End-span
Indicator

Each port has one LINK/ACT

BT Status indicator , whole power indicator
Performance

Store and forward

MAC address table 8K

Switching capacity 12Gbps
Forwarding Rate

100BASE-T:148800pps/port

100BASE-T:1488000pps/port
Port Function Power priority mechanism,fast and forward,MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode
Environment Operating Temperature:-10 -- 55℃
Power

Each Port ≤30W

Whole Power ≤120W

DC 52V 2.3A
Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+Outdoor Industrial Ethernet Switch 8 Port POE PSE 220v AC Input Support PoE+

Order Information

Product Description Order Code

8-port unManaged Gigabit Ethernet switch MSG1008

8-port unmanaged Gigabit power over ethernet switch ​ MSG1008P
