High Speed Acid Copper Plating Process Compatible With Iron Parts Zinc Alloy Plastic Plating
High Speed Acid Copper Plating Process Compatible With Iron Parts Zinc Alloy Plastic Plating
Specifications
Copper Sulfate :
200-220 g/L
Payment Terms :
T/T
Type :
High-Speed Acid Copper Process
Place of Origin :
China
Product Code :
R·G-OUTRE
Features :
Ultra-Fast Deposition, Wide Compatibility
Operating Temperature :
20-30 ℃
Delivery Time :
5-8 work day
Cathode Current Density :
1-6 A/dm²
Model Number :
R·G-OUTRE
MOQ :
25-30kg
Packaging Details :
25kg/drum
Description
R·G-OUTRE High-Speed Acid Copper Plating Process
Performance & Features

Combines the advantages of Cupracid 210 and Cupracid 300; easy bath control and excellent leveling performance.

  1. Minimal pinholes, low internal stress and good ductility of deposits.
  2. Wide current density window; leveling capacity up to 75% to achieve full bright finish.
  3. Ultra-fast deposition rate: approx. 1 μm copper per minute at 4.5 A/dm², shortening plating cycle.
  4. Low coating resistivity, ideal for motor industry with strict requirements on physical properties.
  5. Compatible with various substrates: iron parts, zinc alloy, plastic plating and more.
  6. High impurity loading capacity; activated carbon treatment only required after approx. 800–1000 Ah/L bath usage.
Operating Parameters
Item Concentration Range
Copper Sulfate Pentahydrate (CuSO₄·5H₂O) 200–220 g/L
Sulfuric Acid (Specific gravity=1.84) 50–90 g/L
Chloride Ion 70–150 mg/L (ppm)
Outre Make-Up Agent 4–8 mL/L
Outre A Brightener 0.4–0.6 mL/L
Outre B Brightener 0.4–0.6 mL/L
Operating Temperature 20–30 ℃
Cathode Current Density 1–6 A/dm²
Anode Current Density 0.5–2.5 A/dm²
Anode Material Phosphor copper balls (0.03% P)
Agitation Air agitation + mechanical agitation
