DS-610 Ultra Concentrated Acid Copper Additives With High Bath Stability
DS-610 Ultra Concentrated Acid Copper Additives With High Bath Stability
Specifications
Model Number :
DS-610
Copper Sulfate :
160–240 g/L
Payment Terms :
T/T
Delivery Time :
5-8 work day
Operating Temperature :
18–35 ℃
MOQ :
25-30kg
Chloride Ion :
40–120 mg/L (ppm)
Packaging Details :
25kg/drum
Cathode Current Density :
1–8 A/dm²
Place of Origin :
China
Pure Sulfuric Acid :
40–90 g/L
Brand Name :
AOBANG
Leveling power :
95%
Description
DS-610 Ultra-Concentrated Acid Copper Additive
Performance & Features
  1. Innovative ultra-concentrated composite formula with leveling power up to 95%.
  2. Easy bath control; coatings are free of pinholes, featuring low internal stress and excellent ductility.
  3. High bath stability; crystal clear bright surface eliminates fogging issue.
  4. High impurity tolerance for extended bath service life.

    Fast leveling in low-current zones and uniform coating thickness between high and low current areas. Ideal for automotive parts (aluminum wheel hubs), plastic electroplating and general hardware with premium results.

Operating Parameters
Item Concentration & Range
Copper Sulfate Pentahydrate 160–240 g/L
Pure Sulfuric Acid 40–90 g/L
Chloride Ion 40–120 mg/L (ppm)
DS610 MU Make-up Agent 4–10 mL/L
DS610 A Additive 0.2–0.6 mL/L
DS610 B Additive 0.2–0.6 mL/L
Operating Temperature 18–35 ℃
Cathode Current Density 1–8 A/dm²
Anode Current Density 0.5–3.0 A/dm²
Anode Material Phosphor copper balls (0.03%–0.06% phosphorus)
Agitation Air agitation or mechanical agitation
