Scrape Abrasion Test Apparatus with 0.45mm Abrasion Needle Compliant to ISO6722-1 and ISO19642-2 at 55 Cycles/Min
Scrape Abrasion Test Apparatus with 0.45mm Abrasion Needle Compliant to ISO6722-1 and ISO19642-2 at 55 Cycles/Min
Specifications
Brand Name :
Pego Electronics
Model Number :
PG-SCA
Certification :
CNAS Calibration Certificate
Place of Origin :
China
MOQ :
1 set
Price :
USD1000-USD5000
Payment Terms :
T/T
Supply Ability :
50 sets/month
Delivery Time :
10-20 working days
Packaging Details :
woodencase
Normative standards :
ISO6722-1, ISO19642 -2, DIN72551-5, QC/T-730, JASO D611-94 and VW60306
Diameter of abrasion needle :
0.45mm*1, 0.25mm*1
Needle material :
Spring wire
Frenquency :
55 cyles/min
Groove depth :
0.4mm, 0.8mm
Input :
AC220V, 50Hz/60Hz
Description

Scrape Abrasion Test Apparatus with a 0.45mm abrasion Needle for Testing Automative Cables Compliant to ISO6722-1 and ISO19642-2

  1. Introduction

Scrape abrasion test apparatus is a a specialized device used to test the abrasion resistance of automotive cables, compliant to standards ISO6722-1 clause 5.12.4.2 and figure 7,ISO 19642-2 clause 5.3.2.5 and figure 4, DIN72551-5, QC/T-730, JASO D611-94 and VW60306.

The scrape abrasion test apparatus consisted a device to abrade the surface of the insulation of the test sample and a counter to record the numbers of cycles to failure. The needle abrades through the insulation and makes contact with the conductor, the apparatus will stop automatically. Scrape the sample at a certain speed until the sample cracks or breaks, and record the number of cycles to failure; or apply a certain vertical force to scrape the sample in a fixed cycles and then observe whether the sample has cracks or breakage.

2. Parameters

Diameter of needle

(0.45±0.01) mm*1, (0.25±0.01)mm*1

Type of needle

Spring wire material

Length of abrasion

(15.5±1)mm

Frequency

(50/60±5) cycles/min (adjustable)

Displacement of the needle

≤20mm

Drive mode

Motor-driven

Mass

1N, 4N, 7N

Groove depth

0.4mm, 0.8mm

Number of test station

1

Working power

AC220V/50Hz
