IEC60227 Compliant Cable Bending Test Apparatus with 0.5KG Test Load and 60r/min Oscillating Speed
IEC60227 Compliant Cable Bending Test Apparatus with 0.5KG Test Load and 60r/min Oscillating Speed
Specifications
Brand Name :
Pego Electronics
Model Number :
PG-CBT
Certification :
CNAS Calibration Certificate
Place of Origin :
China
MOQ :
1 set
Price :
USD1000~USD5000
Payment Terms :
T/T
Supply Ability :
50 set/months
Delivery Time :
10-20 working days
Packaging Details :
woodencase
Normative Standards :
IEC60227-2, IEC60227-1
Application :
for checking the mechanical strength of completed cables
Test Current :
0.1A
Test Load :
0.5KG
Oscillating Speed :
60r/min
Swing Angle :
±90 degrees on both sides from vertical
Control Unit :
PLC+touch screen
Input :
220V, 50Hz/60Hz
Description

Cable Bending Test Apparatus for Checking Mechanical Strength of Complete Cables Compliant with IEC60227

  1. Introduction

The cable bending test apparatus is designed to meet the test requirements of IEC60227-2:2003 clause 3.2 and IEC60227-1:1998 clause 5.6.3.2 for checking the mechanical strength of completed cables.

A sample of cord of appropriate length is fixed in the apparatus, and loaded with a weight having a mass of 0.5KG. A current of about 0.1A shall be pass through the conductors. The sample shall be bent backward and forwards in a direction perpendicular to the plane of the axis of the conductors, the two extreme position making a angle of 90° on both sides of the vertical. A flexing is a movement through 180°. The rate of flexing is 60 per minute. Neither interruption of the current nor short circuit between the conductors shall occur.


2. Specification

Working power

220V/50Hz, 300W max

Control system

7 inch LCD touch screen+PLC

Load weights

0.5KG

Working station

1

Oscillating speed

60r/min

Oscillating drive

Step motor

Test times

0-99999 (preset-able)

Oscillating angle

Free setting

angle indicator

0-360°, made of stainless steel

Swing angle

±90° on both sides from vertical

Output current

0.1A

Output power (max)

50W
