IEC60335-2-2 Compliant Abrasion Test Apparatus with 30r/min Crank Speed and 0.1m/min Abrasive Cloth Belt Speed for Current-Carrying Hose Testing
IEC60335-2-2 Compliant Abrasion Test Apparatus with 30r/min Crank Speed and 0.1m/min Abrasive Cloth Belt Speed for Current-Carrying Hose Testing
Specifications
Brand Name :
Pego Electronics
Model Number :
PG-CHA
Certification :
CNAS Calibration Certificate
Place of Origin :
China
MOQ :
1 set
Price :
USD1000~USD5000
Payment Terms :
T/T
Supply Ability :
50 sets/month
Delivery Time :
10-20 working days
Packaging Details :
woodencase
Normative Standard :
IEC60335-2-2, IEC60335-2-24
Application :
for testing the current carry hoses of vacuum cleaners resistant to abrasion
Crank Speed :
30r/min
Weight :
1kg
Moving speed of abrasive cloth belt :
0.1m/min
Input :
AC 220V/50Hz
Description

Abrasion Test Apparatus for Testing the Mechanical Strength of Current-Carrying Hose as Per IEC60335-2-2

1. Introduction

his test apparatus is designed according to IEC60335-2-2 clause 21.102 figure 101 and IEC60335-2-24 clause 21.102 and figure 101, it is applied to test the current carry hoses of vacuum cleaners resistant to abrasion. One end of the hose is attached to the connecting rod of the crank mechanism, the crank rotates at 30r/min resulting in the end of the hose moving horizontally backwards and forwards over a distance of 300mm. The hose is supported by a rotating smooth roller over which a belt of abrasive cloth moves at a speed of 0.1m/min. A mass of 1kg is suspended from the other end of the hose, which is guided to rotation. In the lowest position, the mass has a maximum distance of 600mm from the center of the roller. The test is carried out for 100 revolution of the crank.

2. Parameter

Control units

Button control+meter

Drive mode

AC geared motor

Crank speed

30r/min

Hose moving distance

300mm

Moving speed of abrasive cloth belt

0.1m/min

Abrasive cloth belt

Size P100 as per ISO/DIS644

Weight

1kg

The distance between weight and roller center

600mm

Counter

Setting value: 0-999 (settable)

Real value:display the actual number of tests

Dimension

500mm*800mm*1600mm (W*L*H)

Working power

220V/50Hz
