8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
8 1/2 XD S 6166 AB(24050) Size PDC Drill Bit with GI Cutter Grade and Ultra-Short Body Design for Directional Drilling
Specifications
Delivery Time :
15-45 Days
Nozzle type & count :
M*6
Make-Up length :
224mm
Total flow area :
512mm^2
Packaging Details :
Standard Exported Package
Chip Removal Groove Area Ratio :
54%
Gauge Length :
80mm
Supply Ability :
Stable supply and support for bulk customization
Model Number :
8 1/2 XD S 6166 AB(24050)
IADC code :
S322
Updrill :
6
Approximate Shipping Weight :
32kg
Price :
Negotiable
Recommended Weight on Bit (Maximum Acceptable) :
14-16T(133T)
Place of Origin :
CHINA
Payment Terms :
L/C,D/P,T/T,
Gauge :
42
API Connection :
4-1/2REG
MOQ :
1 Picece(MOQ)
Certification :
API、ISO 9001
Cutter Grade :
GI
body type :
STEEL
Brand Name :
XINGTONG
Face :
50
Make-Up TQ :
17.0-26.4KN.m
Description
Xingtong Drill Bit 8 1/2 XD S 6166 AB(24050)
Positioning

The XD series drill bits are directional drilling tools engineered to meet the rigorous demands of various directional well applications, including coalbed methane drainage directional wells and oil horizontal wells. Incorporating advanced drill-bit design concepts with specialized structural and material optimizations, the XD series delivers highly efficient rock-breaking performance even under complex wellbore trajectory conditions.

Technical Highlights
  • Suitable for use with rotary steerable systems to increase build rates, or with screw motors to enhance directional drilling efficiency
  • Ultra-short body design reduces effective make-up length by 40% compared to conventional drill bits, significantly enhancing deviation-control capability
  • Unique detent-tooth design ensures excellent tool-face stability even under enhanced weight-on-bit during directional sliding operations
  • Maximum build rate when used with a bent sub is ≥30°/30 m, and maximum build rate when used with a rotary steerable system is ≥15°/30 m
Applicable Operating Conditions

The XD directional series is specifically designed for critical drilling sections such as build-up and horizontal sections of directional wells. It can be effectively used in conjunction with downhole screw motors and other directional tools. In demanding applications including coal mine gas drainage boreholes and highly challenging, long-reach wells, this drill bit series has consistently demonstrated outstanding performance, achieving single-trip penetration and rapid rates of penetration.
