12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
12 1/2 XHR 6163 (26003) Size High-RPM PDC Drill Bit for Soft Formations - XHR Series Polycrystalline Diamond Compact Drill Bit
Specifications
Nozzle type& count :
M*9
Make-Up length :
318mm
Chip Removal Groove Area Ratio :
67.6%
Gauge Length :
75mm
Packaging Details :
Standard Exported Package
MOQ :
1 Picece(MOQ)
IADC code :
S222
Gauge :
52
API Connection :
6-5/8REG
Payment Terms :
L/C,D/P,T/T,
Model Number :
12 1/2 XHR 6163 (26003)
Supply Ability :
Stable supply and support for bulk customization
Updrill :
6
Approximate Shipping Weight :
95kg
Place of Origin :
CHINA
Recommended Weight on Bit :
872mm^2
Price :
Negotiable
Make-Up TQ :
50.3-57.5KN.m
Delivery Time :
15-45 Days
Cutter Grade :
GI
Brand Name :
XINGTONG
body type :
STEEL
Certification :
API、ISO 9001
Face :
76
Description
Xingtong Drill Bit 12 1/2 XHR 6163 (26003)
Product Positioning
The XHR series is a high-RPM drill bit engineered for high-speed drilling operations in soft formations. Designed to maximize rate of penetration (ROP), this bit utilizes advanced tooth geometry and hydraulic optimization to deliver superior rock breakage efficiency and rapid cuttings removal, significantly accelerating drilling speed.
Technical Highlights
  • Optimized for high-speed drilling in soft geological formations
  • Hybrid matrix with irregular cutting teeth geometry enhances rock-breaking efficiency while increasing cuttings transport velocity
  • CFD-optimized nozzles and flow passages provide superior cuttings-carrying efficiency during high-speed operations
  • High-strength steel body enables thinner cutter blade design, preventing interference during high mechanical drilling rates
Applicable Operating Conditions
Ideal for drilling intervals in soft to medium-hard formations where accelerated penetration is required. Specifically designed for operations targeting the highest possible mechanical drilling rate.
