Specifications
Supply Ability :
Stable supply and support for bulk customization
IADC code :
S432
Brand Name :
XINGTONG
Gauge :
39
API Connection :
3-1/2REG
Updrill :
7
Approximate Shipping Weight :
21kg
Recommended Weight on Bit（Maximum Acceptable） :
10-12T （78T）
Packaging Details :
Standard Exported Package
Price :
Negotiable
Nozzle type & count :
M*8
Make-Up length :
244mm
Total flow area :
462mm^2
Chip Removal Groove Area Ratio :
65.4%
Gauge Length :
61mm
Model Number :
6 XH S 7139 A(24023)
Delivery Time :
15-45 Days
Cutter Grade :
GI
Place of Origin :
CHINA
body type :
STEEL
Face :
32
MOQ :
1 Picece(MOQ)
Certification :
API、ISO 9001
Payment Terms :
L/C,D/P,T/T,
Make-Up TQ :
7.1-11.5KN.m
Description
Xingtong Drill Bit 6 XH S 7139 A(24023)
Product Positioning

The XH series represents Xingtong's high-durability drill bit lineup engineered specifically for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, this series incorporates enhanced wear-resistant materials and optimized structural design to deliver superior performance in demanding drilling conditions.

Technical Highlights
  • Enhanced performance in hard formations to extend drill bit life and improve penetration rates
  • Optimized crown geometry ensures uniform load distribution, reduces stress on individual teeth, and minimizes core gouging risk
  • High-performance imported PDC cutters selected for superior shoulder wear resistance and impact resistance
  • Unique rear-flute design maintains cutting aggressiveness while enhancing overall drill bit durability
Applicable Operating Conditions

Ideal for drilling operations in extremely hard and highly abrasive formations where extended tool life and higher penetration rates are critical requirements.
