Specifications
Nozzle type & count :
M*5
Make-Up length :
225mm
Total flow area :
485mm^2
Certification :
API、ISO 9001
Chip Removal Groove Area Ratio :
67.5%
Gauge Length :
55mm
Model Number :
6 XHR S 5166 K(24035)
Price :
Negotiable
Payment Terms :
L/C,D/P,T/T,
IADC code :
S322
MOQ :
1 Picece(MOQ)
Updrill :
5
Approximate Shipping Weight :
20kg
Recommended Weight on Bit（Maximum Acceptable） :
10-12T （78T）
Place of Origin :
CHINA
Gauge :
18
API Connection :
3-1/2REG
Brand Name :
XINGTONG
Cutter Grade :
GI
Delivery Time :
15-45 Days
Supply Ability :
Stable supply and support for bulk customization
body type :
STEEL
Face :
23
Packaging Details :
Standard Exported Package
Make-Up TQ :
7.1-11.5KN.m
Description
Xingtong Drill Bit 6 XHR S 5166 K(24035)
Product Positioning
The XHR series is a high-RPM drill bit engineered specifically for high-speed drilling operations in soft formations. Designed to maximize rate of penetration (ROP) in soft geological conditions, this drill bit utilizes advanced tooth geometry and hydraulic optimization to deliver superior rock breakage efficiency and rapid cuttings removal, resulting in significantly increased drilling speeds.
Technical Highlights
  • Optimized for high-speed drilling performance in soft formations
  • Hybrid matrix with irregularly shaped cutting teeth enhances rock-breaking efficiency while accelerating cuttings transport velocity
  • CFD-optimized nozzles and flow passages provide superior cuttings-carrying efficiency during high-speed drilling operations
  • High-strength steel body enables thinner cutter blade thickness, preventing interference at the blade rear during high mechanical drilling rates
Applicable Operating Conditions
Ideal for drilling intervals in soft to medium-hard formations where accelerated penetration is required. Specifically designed for operations targeting the highest possible mechanical drilling rate to optimize overall drilling efficiency.
