Specifications
Brand Name :
Nexperia
Model Number :
74HC1G08GV,125
Certification :
ROHS
Place of Origin :
CN
MOQ :
1
Price :
consult with
Payment Terms :
T/T,Western Union
Supply Ability :
100000
Delivery Time :
5-8days
Packaging Details :
T/R
Description :
Single 2-input AND gate
VCC (V) :
2.0 - 6.0
Logic switching levels :
CMOS
Output drive capability (mA) :
± 5.2
tpd (ns) :
7.0
fmax (MHz) :
36
Description
74HC1G08GV,125 Single 2-Input AND Gate
The 74HC1G08GV,125 is a single 2-input AND gate featuring input clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Key Features
  • Wide supply voltage range from 2.0 V to 6.0 V
  • CMOS low power dissipation
  • High noise immunity
  • Symmetrical output impedance
  • Balanced propagation delays
  • Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
  • Input levels:
    • For 74HC1G08: CMOS level
    • For 74HCT1G08: TTL level
  • Complies with JEDEC standards:
    • JESD8C (2.7 V to 3.6 V)
    • JESD7A (2.0 V to 6.0 V)
  • ESD protection:
    • HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
    • CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
  • Specified from −40 °C to +85 °C and −40 °C to +125 °C
Product Variants
Type Number Temperature Range Package Description Version
74HC1G08GW
74HCT1G08GW		 -40 °C to +125 °C TSSOP5 plastic thin shrink small outline package; 5 leads; body width 1.25 mm SOT353-1
74HC1G08GV
74HCT1G08GV		 -40 °C to +125 °C SC-74A plastic surface-mounted package; 5 leads SOT753
74HC1G08GZ
74HCT1G08GZ		 -40 °C to +125 °C XSON5 plastic thermal enhanced extremely thin small outline package with side-wettable flanks (SWF); no leads; 5 terminals; body 1.1 * 0.85 * 0.5 mm SOT8065-1
74HC1G08GV,125 A Single 2-input AND Gate Inputs Include Clamp Diodes. Thisenables The Use Of Current Limiting Resistors To Interface Inputs To Voltages In Excess Of VCC 74HC1G08GV,125 A Single 2-input AND Gate Inputs Include Clamp Diodes. Thisenables The Use Of Current Limiting Resistors To Interface Inputs To Voltages In Excess Of VCC 74HC1G08GV,125 A Single 2-input AND Gate Inputs Include Clamp Diodes. Thisenables The Use Of Current Limiting Resistors To Interface Inputs To Voltages In Excess Of VCC
Packaging & Shipping
Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.
Frequently Asked Questions
How to obtain the price?
We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.
What is your delivery time?
Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.
What are your payment terms?
Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.
What are the shipping options?
Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
