Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection
Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection
Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection
Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection
Specifications
Brand Name :
Dexon
Model Number :
DX081PB
Certification :
CE、RoHS、ISO、IEC、IALA、IMO
Place of Origin :
Chengdu
MOQ :
1
Price :
USD 2000~3000
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram,L/C
Supply Ability :
10000/month
Delivery Time :
3～10 days
Packaging Details :
cartons/pallets
Lifespan :
15 Years
Materia :
FRP (Fiberglass Reinforced Plastic)
Message :
Message 21, 6, 8, 14, Supports Multiple Formats
AIS Transmission Distance :
20NM~25NM
Operating Temperature :
-35°C to +60°C
Protection Level :
IP68
Certifications :
CE, RoHS, ISO,IEC, IALA
applications :
Pre-Installation Testing Routine Field Maintenance AIS AtoN Demonstration & Training
Description

A rechargeable AIS AtoN base station is perfect for channel markers

and solar navigation lights

Unlike traditional AIS base stations, the DX081PB enables users to inspect all beacons and AtoNs in a given area from the shore, eliminating the need for vessel boarding. Its compact design and real-time data access enable teams to identify specific device issues and schedule targeted maintenance, while its dual-mode AIS communication helps them to do so. This significantly reduces labour costs and downtime, while improving the accuracy of inspection routines.

Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection

Core advantages

  1. It enables the remote inspection of all AtoNs within range, without the need for a vessel.
  2. Access to real-time AIS data ensures precise fault detection and diagnostics.
  3. Compact and efficient, making it ideal for rapid deployment along coastlines.
  4. Dual-mode AIS communication ensures broad compatibility and accurate tracking.
  5. Cuts labour costs by eliminating the need for time-consuming manual inspection trips.
  6. Allows for smarter maintenance scheduling through targeted, device-level analysis.

Technical specification

Category

Specification

Details
Main features
 Operating Voltage DC 5.5–8.3V
Battery Capacity 77Wh (10.4Ah @ 7.4V)
Standby Time ≥20 hours continuous operation
Frequency Range 156.025MHz–162.025MHz
Air Transmission Rate 9600bps ±50ppm
Sensitivity ≤−110dBm
Modulation Mode GMSK/FSK
Interface RS232 Data Interface
Transmission Power ≤6W
Spurious Emission Suppression ≤−70dBc
Operating Temperature −35°C to +60°C
Dimensions 300mm × 150mm × 50mm
Weight ≤3kg

Drawings

Handheld AIS Base Station Device Marine Field Testing & Signal Verification For Buoy Inspection

Application

  • Pre-Installation Testing
  • Onsite Buoy & Beacon Inspection
  • Routine Field Maintenance
  • Temporary Deployment in Field Projects
  • AIS AtoN Demonstration & Training

FAQ

1, Does it support remote AtoN inspection?
Yes. Monitors all nearby AtoNs—no vessel needed.

2, How is fault detection handled?
Real-time AIS data enables precise diagnostics and alerts.

3, Is it suitable for coastal deployment?
Yes. Compact and efficient—perfect for fixed coastal stations.

4, What AIS modes are supported?
Dual-mode AIS ensures full compatibility and accurate tracking.

5, Can it reduce inspection costs?
Absolutely. No need for manual trips or vessel deployment.

6, How does it support smarter maintenance?
Offers targeted data for predictive maintenance and scheduling.
