Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Specifications
driven type :
Electric
key selling points :
High Productivity
After-sales Service Provided :
Video Technical Support, Online support, Field installation, commissioning and training
Filling nozzle :
customized
Payment Terms :
TT
dimension(l*w*h) :
440*330*330mm
machinery test report :
Provided
filling nozzle :
1, 2, 4
packaging type :
Case
Weight (KG) :
11
Flow capacity :
7L/min; 14L/Min.
MOQ :
1
Voltage :
220v
video outgoing-inspection :
Provided
Packaging Details :
wooden cases
packaging material :
Wood
Packing type :
Cartons+ Wooden Packaging
Packing Size :
460*350*350mm
Filling accuracy :
±1%
Degree of automation :
Semi-automatic
core components :
Pump, PLC
Weight :
about 10 KG
Place of Origin :
Guangdong, China
Price :
£338.29-375.88
Supply Ability :
10000 set
automatic grade :
Semi-Automatic
Keywords :
semiauto liquid filling machine
warranty :
1 Year
filling accuracy :
99%
Product name :
Semi-automatic shampoo lotion bottle liquid filling machine
Packing weight :
13kg
Delivery Time :
7 work days
application :
Food, Chemical
Filling Volume :
100mL, 200mL, 500 mL, 300mL, 400 mL
Brand Name :
Cosmati
filling material :
Beer, Milk, Water, Oil, Juice
Description
Desktop Toner Juice Beverage Milk Filling Machine Perfume Manual Filler Olive Oil Liquid Essential Oil Serum Bottling Machine

Introduction

The Desktop Magnetic Pump Filling Machine is designed for quantitative filling of toner, serum, olive oil, juice, beverage, cosmetic liquids and other low-viscosity or free-flowing products.

The machine uses a magnetic gear pump metering system to transfer and dispense liquid without a conventional mechanical shaft connection between the pump and motor. This compact semi-automatic design provides convenient filling volume adjustment, stable liquid transfer and easy operation for small and medium batch production.

Filling time, waiting time and operating parameters can be adjusted through the digital control panel. Manual and automatic filling modes support different production requirements, while the compact desktop structure saves workspace and is suitable for laboratories, cosmetic factories, food producers and startup production lines.

Key Features

  1. Magnetic pump filling system provides stable liquid transfer and quantitative dispensing.
  2. Suitable for toner serum olive oil juice beverage water cosmetic liquid and similar products.
  3. Compact desktop structure saves production space.
  4. Manual and automatic filling modes support flexible operation.
  5. Filling time and waiting time are adjustable through the control panel.
  6. Different pump sizes support multiple filling volume ranges.
  7. 1 2 and 4 nozzle configurations can be customized.
  8. Reference flow capacities include approximately 7L/min and 14L/min.
  9. Foot pedal control supports convenient semi-automatic filling.
  10. Filling tubing can be selected according to different liquid characteristics.
  11. Easy product changeover suits multi-product small batch production.
  12. Machinery test report and outgoing inspection video can be provided.

Technical Data

Product name
Semi Automatic Liquid Filling Machine
Filling volume
5-150ml,30-500ml,60-1000ml,250-2500ml,500-5000ml
Filling nozzle
1, 2 pcs or customized
Big pump capacity
>14L/min
Small pump capacity
>7L/min
Material
Stainless steel
Packaging Details
Plywood box , match 1 packing list , 1 set wrench , 1pc English manual and some easy damage parts.
Delivery Time
Shipped in 3-5 days after payment

Factory profile
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler


Engineer case
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Trade show participation
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Packaging & shipping specifications
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler
Application
Desktop Magnetic Pump Filling Machine Toner Serum Olive Oil Juice Beverage Filler

FAQ

1. What liquids can this machine fill?

It is suitable for toner, serum, olive oil, juice, beverage, water and other low-viscosity liquids.

2. What filling system does the machine use?

The machine uses a magnetic pump metering and conveying system for quantitative liquid filling.

3. What filling range is available?

Different pump models can support approximately 5ml to 5000ml filling ranges. The correct pump should be selected according to the target filling volume.

4. What is the filling accuracy?

The supplied specifications indicate approximately ±1% reference accuracy. Actual performance depends on liquid properties, filling volume and machine settings.

5. Can it fill toner and facial serum?

Yes. Toner, essence and free-flowing serum are key applications for this desktop liquid filler.
