Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Specifications
driven type :
Pneumatic
filling material :
Milk, Water, Oil, Juice
Weight (KG) :
50
Filling volume :
5-60; 10-100; 25-250; 50-500; 100-1000(ml)
Price :
$950-1,350
warranty :
1 Year
video outgoing-inspection :
Provided
After-sales Service Provided :
Online support
Place of Origin :
Guangdong, China
filling nozzle :
1
Core Components :
Pump
Brand Name :
Cosmati
packaging type :
Case
Filling Volume :
200mL, 100mL, 500 mL, 300mL, 400 mL, 1L
Production capacity :
1-60 (cans/minute)
packaging material :
Wood
MOQ :
1
dimension(l*w*h) :
550*580*1600 mm(21.65*22.83*62.99in)
core components :
Motor, Pressure Vessel, PLC, Gear, Other
Packaging Details :
wooden cases
Delivery Time :
7 work days
Supply Ability :
10000 set
Applicable bottle height :
30-200(mm)
Degree of automation :
Semi-automatic
Applicable bottle diameter :
10-120(mm)
key selling points :
High Productivity
machinery test report :
Provided
Key words :
paste filling machine pneumatic
Payment Terms :
TT
application :
Food, Chemical
Product name :
Semi-automatic paste filling machine
filling accuracy :
±0.5%
automatic grade :
Semi-Automatic
Size :
550*580*1600mm
Description
Volumetric Filling Machine Cosmetic Skincare Paste Cream Filler Palm Oil Pneumatic Shea Butter Filling Machine

Introduction

This Pneumatic Paste Filling Machine is designed for accurate filling of cream, lotion, paste and other liquid or semi-viscous products.

The machine uses a fully pneumatic filling system and requires an external compressed-air supply. The standard 30L stainless steel hopper provides convenient gravity feeding, while the product-contact parts are made of SS316L stainless steel for easy cleaning and good corrosion resistance.

A sanitary clamp connection allows quick disassembly of product-contact components for cleaning and maintenance. Different filling nozzles and filling ranges can be selected according to bottle size, product viscosity and required filling volume.

The compact single-nozzle design is suitable for flexible small and medium batch production in cosmetic, personal care, daily chemical and related industries.

Features

  1. Fully pneumatic filling system provides stable operation and simple control.
  2. Standard 30L stainless steel hopper supports convenient gravity feeding.
  3. SS316L product-contact parts are suitable for cream, lotion and paste filling applications.
  4. Adjustable filling volume supports different container sizes and production requirements.
  5. Different filling nozzles can be changed according to bottle opening and filling volume.
  6. Sanitary clamp connections allow quick disassembly and easier cleaning.
  7. Single filling nozzle design is suitable for flexible batch production and frequent product changes.
  8. Foot pedal control allows the operator to start each filling cycle conveniently.
  9. Optional automatic feeding system can reduce manual material replenishment.
  10. Filling cylinder, hopper size and nozzle configuration can be customized according to the product.
Model
Filling Volume
Filling Speed
Pressure Supply
CM-GT-5
5-50ml
10-45 bpm
0.2-0.6 Mpa
CM-GT-10
10-120ml
10-35 bpm
0.2-0.6 Mpa
CM-GT-25
25-250ml
10-30 bpm
0.2-0.6 Mpa
CM-GT-50
50-500ml
10-30 bpm
0.2-0.6 Mpa
CM-GT-100
100-1000ml
10-25 bpm
0.2-0.6 Mpa
CM-GT-250
250-2500ml
5-18 bpm
0.2-0.6 Mpa
CM-GT-500
500-5000ml
5-12 bpm
0.2-0.6 Mpa


Factory profile
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Engineer case
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Trade show participation
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Packaging & shipping specifications
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler
Application
Semi Automatic Volumetric Filling Machine Gear Pump Cosmetic Cream Shea Butter Filler

FAQ

Q1: What products can this pneumatic filling machine fill?
A: It is suitable for cream, lotion, gel, ointment, shampoo, liquid soap and other liquid or semi-viscous products.

Q2: What is the filling range?
A: Filling configurations from approximately 5 to 1000 mL/g are available. The actual range depends on the selected filling cylinder and machine configuration.

Q3: Does one machine cover the entire 5–1000 mL range?
A: Not necessarily. Different filling volumes may require different cylinder or nozzle configurations. The required filling range should be confirmed before ordering.

Q4: What is the standard hopper capacity?
A: The standard hopper is approximately 30L. Other hopper sizes can be customized according to production requirements.

Q5: What material is used for product-contact parts?
A: The product-contact parts are made of SS316L stainless steel.
