M25 Male Female Bulkhead Connector Quick Release 5 Pin Panel Mount Connector
M25 5 Pin Electrical Wire To Board Connectors 300V Round Waterproof Connector
Product Overview
This 20A 300V M25 male-female bulkhead connector features a 5-pin panel mount design with quick-release structure. Designed exclusively for power supply scenarios, it serves as a dedicated power connection accessory for panel-mounted equipment in industrial and outdoor applications, balancing convenience and stability.
Compliant with the M25 standard interface, the 5-pin precision layout supports 20A current and 300V voltage transmission, providing stable power supply with low loss for medium-power equipment. The male-female plug-in combined with bulkhead design is ideal for panel mount scenarios, offering excellent sealing performance to effectively block dust and moisture.
The quick-release structure enables tool-free plugging, unplugging, and separation by hand, significantly improving installation and maintenance efficiency. The shell is constructed from high-insulation, aging-resistant materials, ensuring firm panel installation without loosening, adapting to various complex working conditions for long-term stable power supply.
Main Features
  • Push lock quick release system
  • Multicore options: 2Pin, 3Pin, 4Pin, 5Pin, 3+2Pin, 3+3Pin, 3+9Pin, 3+13Pin, 5+2Pin and 2+20Pin available
  • Field assembly version: both wire to wire and wire to board options
  • High current rated waterproof connector suitable for up to 20A continuous operation
  • Cable assembly service supported - custom orders welcome
  • OEM/ODM welcome
Electrical Parameters
Number of Poles 5Pin waterproof connector
Current Rating 20A max
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Application Industries
  • Communications Application
  • Product coding machines
  • Inventory product coding
  • Inkjet systems
  • Solar System
  • Industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic & pathology equipment
  • Communications equipment
  • Heavy machinery
Operation Parameters
Voltage Rating 600VAC max
Current Rating 30A max
Min Wire Size OD 6.5mm ~ 10mm
Max Wire Size OD 10.5mm ~ 18mm
Max Cable Cross Section Area 0.5mm² ~ 6.0mm²
Production Dimension
M25 Male Female Bulkhead Connector Quick Release 5 Pin Panel Mount Connector
More Technical Details
M25 Male Female Bulkhead Connector Quick Release 5 Pin Panel Mount Connector
Frequently Asked Questions
How can I get samples?
We're pleased to offer samples, with freight costs covered by the customer. Please provide your courier account number and detailed address, and we'll dispatch samples immediately.
What is your Minimum Order Quantity (MOQ)?
MOQ varies by product type—typically 500 units for standard models and 1000 units for customized items. Lower MOQ can be negotiated for trial orders or long-term cooperation.
Is there a discount for large-quantity orders?
Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the pricing. Please share your expected quantity for a customized quotation.
What payment methods do you accept?
We support mainstream international payment methods: T/T (Telegraphic Transfer), L/C (Letter of Credit), PayPal, and West Union. For large orders, our standard terms are 30% down payment + 70% balance before shipment.
